| Citation: | MA Hongwei, HE Xiang, SHAN Xiaoming, et al. A method for measuring 3-D unsteady flow at exits of a compressor rotor using combined probes[J]. Journal of Aerospace Power, 2022, 37（10）：2253-2260 doi: 10.13224/j.cnki.jasp.20220276
|
A method for measuring 3-D unsteady flow at an exit of a transonic multistage compressor rotor was presented by using combined high-response pressure probes consisting of a cylinder 1-hole probe and a tip-wedged 1-hole probe, which were calibrated in a wind tunnel. The probes were put in the inter-stage at the same axial and radial but different tangential positions with the help of two traverse mechanisms, and unsteady pressure data were obtained utilizing a phase-locked technique at different angular positions. Distributions of 3-D flow parameters were obtained through data processing. Result showed that the combined probes were characterized by small size, high frequency, wide measurement range and weak interrupt compared with other current 3-D high-response probes, while the method can obtain flow pitch angle and more accurate total pressure, static pressure and Mach number compared with 2-D high-response probe techniques. The combined-probe technique provides a feasible 3-D flow measurement method for flow diagnosis in small multistage compressors.
