The adaptive cycle engine is an important candidate power unit for the next generation of aircraft. After a brief introduction of the research progress at home and abroad, focuses were put on the overall design research of the adaptive cycle engine currently carried out. Firstly, the overall performance scheme and structural form of the typical adaptive cycle engine were introduced. Then, the performance benefits and costs of the adaptive cycle engine were discussed. Finally, the overall design development trend of the future was presented. It is believed that the overall design of adaptive cycle engines in the fu-ture should be carried out under the parallel multi-dimensional and multi-disciplinary optimization system, considering the influences of multi-source uncertainties. Hybrid-dimensional simulation methods can be applied to evaluate the technical characteristics of novel components, and the comprehensive performance optimization of aircraft/engines can be carried out according to the requirements of flight missions.
