| Citation: | DU Mingjie, LÜ Xufei, WEI Jinzhou, et al. Inversion of thermal parameters of aircraft fuel tank based on particle swarm optimization[J]. Journal of Aerospace Power, 2023, 38（1）：250-256 doi: 10.13224/j.cnki.jasp.20210360
|
In order to obtain the thermal parameters of aircraft fuel tank for quantitative evaluation of flammability, relying on the assumption of establishing fuel tank thermal model with lumped parameter method, the inversion of thermal parameters of a certain aircraft central fuel tank was explored based on particle swarm optimization algorithm and flight test data. Four different parameters were selected as the objective functions to study the influences of the selection of the objective function on the inversion results of thermal parameters. Results showed that the output value of the fuel tank thermal parameter model was consistent with the experimental value, which proved the effectiveness of the method; the maximum deviation between the model output and the experimental value was 2.62 K; finally, adding a penalty term to the overall mean square error could make the inversion thermal parameter model meet the requirements of airworthiness regulations.
| [1] |
魏书有.飞机燃油箱可燃性暴露评估研究[D].天津: 中国民航大学,2013.
WEI shuyou. Aircraft fuel tank flammability exposure evaluation research[D].Tianjin: Civil Aviation University of China,2013.(in Chinese)
|
| [2] |
Federal Aviation Administration. Reduction of fuel tank flammability in transport category airplane:Amendment Nos. 25-125[S].Washington DC: Federal Register,2008:14-15.
|
| [3] |
Aviation Rulemaking Advisory Committee.Fuel tank harmonization working group final report[R].Washington DC: Aviation Rulemaking Advisory Committee,1998.
|
| [4] |
Federal Aviation Administration. A review of the flammability hazard of jet a fuel vapor in civil transport aircraft fuel tanks[R].DOT/FAA/AR-98/26,1998.
|
| [5] |
SUMMER S M .Mass loading effects on fuel vapor concentration in an aircraft fuel tank ullage[R].DOT/FAA/AR-99/65,1999.
|
| [6] |
SUMMER S M.Ground and flight testing of Boeing 737 center wing fuel tank inerted with nitro-gen-enriched air[R].DOT/FAA/AR-01/63,2001.
|
| [7] |
CAVAGE W M,SUMMER S.A study of flammability of commercial transport airplane wing fuel tanks[R].DOT/FAA/AR-08/8,2008
|
| [8] |
中国民用航空局.运输类飞机适航标准:CCAR-25-R4[S].北京:中国民用航空局,2011:256.
|
| [9] |
张瑞华,刘卫华,刘春阳,等. 运输类飞机燃油箱可燃性适航符合性方法[J]. 航空动力学报,2020,35(5): 1099-1108.
ZHANG Ruihua,LIU Weihua,LIU Chunyang,et al. Flammability and airworthiness compliance method of fuel tank for transport aircraft[J]. Journal of Aerospace Power,2020,35(5): 1099-1108. (in Chinese)
|
| [10] |
郭军亮,周宇穗,王澍,等. 飞机燃油箱可燃性定量分析的燃油箱热参数计算方法研究[J]. 民用飞机设计与研究,2011(3): 20-22. doi: 10.3969/j.issn.1674-9804.2011.03.008
GUO Junliang,ZHOU Yusui,WANG Shu,et al. Study of fuel tank thermal data calculating method for aircraft fuel tank flammability quantitative analysis[J]. Civil Aircraft Design and Research,2011(3): 20-22. (in Chinese) doi: 10.3969/j.issn.1674-9804.2011.03.008
|
| [11] |
郭军亮.民用飞机燃油箱热特性数值仿真[J].航空计算技术2013,43(1):65-68.
GUO Junliang.Numerical simulation on fuel tank thermal characters for civil aircraft[J].Aeronautical Computing Technique,2013,43(1):65-68. (in Chinese)
|
| [12] |
吕亚国,任国哲,刘振侠,等. 飞机燃油箱热分析研究[J]. 推进技术,2015,36(1): 61-67.
LÜ Yaguo,REN Guozhe,LIU Zhenxia,et al. Thermal analysis of fuel tank for aircraft[J]. Journal of Propulsion Technology,2015,36(1): 61-67. (in Chinese)
|
| [13] |
祖伟. 基于粒子群优化算法的水下潜器实时路径规划技术研究[D]. 哈尔滨: 哈尔滨工程大学,2008.
ZU Wei. Real-time path planning system based on PSO for underwater vehicles[D]. Harbin: Harbin Engineering University,2008. (in Chinese)
|
| [14] |
韩颜,许燕,周建平. 粒子群-蚁群融合算法的机器人路径规划[J]. 组合机床与自动化加工技术,2020, 62(2): 47-50.
HAN Yan,XU Yan,ZHOU Jianping. A fusion algorism of particle swam and ant colony optimization for robot path planning[J]. Modular Machine Tool and Automatic Manufacturing Technique,2020, 62(2): 47-50. (in Chinese)
|
| [15] |
刘坤,谭营,何新贵. 基于粒子群优化的过程神经网络学习算法[J]. 北京大学学报(自然科学版),2011,47(2): 238-244.
LIU Kun,TAN Ying,HE Xingui. Particle swarm optimization based learning algorithm for process neural networks[J]. Acta Scientiarum Naturalium Universitatis Pekinensis,2011,47(2): 238-244. (in Chinese)
|
| [16] |
CHRISTOPHER K M,KEVIN D,SEPPIJ.Bayesian optimization models for particle swarms[R].New York, US: the Conference on Genetic and Evolutionary Computation,2005.
|
| [17] |
王峰,周宜红,赵春菊,等. 基于混合粒子群算法的特高拱坝不同材料热学参数反演分析[J]. 清华大学学报(自然科学版),2021,61(7): 747-755.
WANG Feng,ZHOU Yihong,ZHAO Chunju,et al. Thermal parameter inversion for various materials of super high arch dams based on the hybrid particle swarm optimization method[J]. Journal of Tsinghua University(Science and Technology),2021,61(7): 747-755. (in Chinese)
|
| [18] |
王乐洋,靳锡波,许光煜. 断层参数反演的动态惯性因子的粒子群算法[J]. 武汉大学学报(信息科学版),2021,46(4): 510-519.
WANG Leyang,JIN Xibo,XU Guangyu. Particle swarm optimization algorithm with dynamic inertia factors for inversion of fault parameters[J]. Geomatics and Information Science of Wuhan Universty,2021,46(4): 510-519. (in Chinese)
|
