三点接触球轴承多点接触形成机制与临界条件界定

张屹立; 邱明; 周大威; 毕明龙

doi:10.13224/j.cnki.jasp.20250179

三点接触球轴承多点接触形成机制与临界条件界定

doi: 10.13224/j.cnki.jasp.20250179

张屹立^1,,
邱明^1,*, ,,
周大威²,
毕明龙²

1.
河南科技大学机电工程学院，河南洛阳，471003
2.
中国航发哈尔滨轴承有限公司，哈尔滨，150025

基金项目: 国家自然科学基金（52275186）；中原学者资助项目（项目号244000510001）

详细信息

作者简介:
张屹立（2001-），男，硕士，主要从事轴承设计及理论研究。E-mail：z2868333919@163.com

通讯作者:
邱明（1969-），女，教授，博士，主要从事轴承设计及理论研究。E-mail：qiuming@haust.edu.cn

中图分类号: V232；TH133.3
计量
- 文章访问数: 73
- HTML浏览量: 87
- PDF量: 3
- 被引次数: 0
出版历程
- 收稿日期: 2025-04-15
- 网络出版日期: 2026-08-28

Production mechanism and critical conditions definition of multi-point contact for three-point contact ball bearings

Zhang Yili^1
,,
Qiu Ming^{1,*
, ,},
Zhou Dawei²,
Bi Minglong²

1.
School of Mechatronics Engineering，Henan University of Science and Technology，Luoyang Henan 471003，China
2.
Harbin Bearing Company Limited，Aero Engine Corporation of China，Harbin 150025，China

摘要

摘要:
针对三点接触球轴承因钢球与沟道多点接触引发的失效问题，选取某型号三点接触球轴承为研究对象，运用动力学模型分析了结构参数与工况条件变化时钢球-沟道发生多点接触的形成机制，得到了钢球与副承载内圈接触点数量的变化规律。这些规律揭示：基础工况下，内圈沟曲率系数小于0.5058、或外圈沟曲率系数大于0.5134、或垫片厚度大于0.60 mm时，轴承发生多点接触；非基础工况下，载荷比大于等于0.35 时轴承脱离多点接触，高转速和大径向载荷需更高的载荷比以避免发生多点接触。另外，构建了多因素下多点接触状态临界条件的量化图谱，界定了不同垫片厚度下发生多点接触的内、外圈沟曲率系数临界值，以及不同径向载荷下发生多点接触的载荷比和转速临界值。该研究从设计和服役角度为避免三点接触球轴承发生多点接触与磨损失效提供了指导。
- 三点接触球轴承 /
- 多点接触 /
- 磨损失效 /
- 结构参数 /
- 工况参数 /
- 临界条件
Abstract:
To address the failure caused by multi-point contact between steel balls and raceways in three-point contact ball bearings, this study took a specific model of three-point contact ball bearing as the research object, and a dynamic model was adopted to analyze the production mechanisms of multi-point contact under variations in structural and operating parameters. And then change rule of the number of contact points between steel balls and the non-main loading inner-half ring (NMLIHR) was obtained. The results reveal that under the basic working conditions, multi-point contact occurs when the inner ring groove curvature coefficient drops below 0.5058 or the outer ring groove curvature coefficient rises above 0.5134, or the gasket thickness exceeds 0.60 mm. Under non-basic working conditions, the multi-point contact phenomenon can disappear when the load ratio is more than 0.35. Further, higher load ratios are required to prevent multi-point contact under conditions of elevated rotational speeds and large radial loads. In addition, the quantitative maps of critical conditions under multi-parameter influences were developed, which could determine the critical threshold values of inner and outer groove curvature coefficients corresponding to different gasket thicknesses, and the critical threshold values of load ratio and rotational speed corresponding to different radial loads. The research findings provide the guidance for avoiding multi-point contact and wear failure in three-point contact ball bearings from both design and service perspectives.
- three-point contact ball bearing /
- multi-point contact /
- wear failure /
- structural parameters /
- working condition parameters /
- critical conditions

HTML

图 1 三点接触球轴承钢球-沟道接触状态示意图

Figure 1. Schematic diagram of ball-raceway contact state in three-point contact ball bearing

下载: 全尺寸图片幻灯片

图 2 三点接触球轴承几何结构示意图

Figure 2. Schematic diagram of three-point contact ball bearing geometric structure

下载: 全尺寸图片幻灯片

图 3 打滑率随轴向载荷变化曲线

Figure 3. Variation curves of skidding rate with axial load

下载: 全尺寸图片幻灯片

图 4 不同内圈沟曲率系数下钢球-沟道接触应力分布（单位：MPa）

Figure 4. Ball-raceway contact stress distribution under varying inner ring groove curvature coefficients （unit: MPa）

下载: 全尺寸图片幻灯片

图 5 副承载内圈钢球-沟道接触点数量随内圈沟曲率系数变化曲线

Figure 5. Variation curves of ball-raceway contact points in NMLIHR with inner ring groove curvature coefficients

下载: 全尺寸图片幻灯片

图 6 不同外圈沟曲率系数下钢球-沟道接触应力分布（单位：MPa）

Figure 6. Ball-raceway contact stress distribution under varying outer ring groove curvature coefficients （unit: MPa）

下载: 全尺寸图片幻灯片

图 7 副承载内圈钢球-沟道接触点数量随外圈沟曲率系数变化曲线

Figure 7. Variation curves of ball-raceway contact points in NMLIHR with outer ring groove curvature coefficient

下载: 全尺寸图片幻灯片

图 8 不同垫片厚度下钢球-沟道接触应力分布（单位：MPa）

Figure 8. Ball-raceway contact stress distribution under varying gasket thickness （unit: MPa）

下载: 全尺寸图片幻灯片

图 9 副承载内圈钢球-沟道接触点数量随垫片厚度变化曲线

Figure 9. Variation curves of ball-raceway contact points in NMLIHR with gasket thickness

下载: 全尺寸图片幻灯片

图 10 内、外圈沟曲率系数与垫片厚度作用下副承载内圈钢球-沟道接触点数量

Figure 10. Number of ball-raceway contact points in NMLIHR under the influence of inner and outer ring groove curvature coefficient and gasket thickness

下载: 全尺寸图片幻灯片

图 11 垫片厚度对不发生多点接触的临界内、外圈沟曲率系数的影响

Figure 11. Influence of gasket thickness on critical inner and outer ring groove curvature coefficient for avoiding multi-point contact

下载: 全尺寸图片幻灯片

图 12 不同载荷比下钢球-沟道接触应力分布（单位：MPa）

Figure 12. Ball-raceway contact stress distribution under varying load ratios （unit：MPa）

下载: 全尺寸图片幻灯片

图 13 副承载内圈钢球-沟道接触点数量随载荷比变化曲线

Figure 13. Variation curves of number of ball-raceway contact points in NMLIHR with load ratio

下载: 全尺寸图片幻灯片

图 14 不同径向载荷下载荷比对副承载内圈钢球-沟道接触点数量的影响

Figure 14. Influence of load ratio on number of ball-raceway contact points in NMLIHR under different radial loads

下载: 全尺寸图片幻灯片

图 15 不同转速下载荷比对副承载内圈钢球-沟道接触点数量的影响

Figure 15. Influence of load ratio on number of ball-raceway contact points in NMLIHR under different rotational speeds

下载: 全尺寸图片幻灯片

图 16 转速、径向载荷和载荷比作用下副承载内圈钢球-沟道接触点数量

Figure 16. Number of ball-raceway contact points in NMLIHR under the influence of rotational speed, radial load and load ratio

下载: 全尺寸图片幻灯片

图 17 径向载荷对不发生多点接触的临界转速和载荷比的影响

Figure 17. Influence of radial load on critical rotational speed and load ratio for avoiding multi-point contact

下载: 全尺寸图片幻灯片

表 1 轴承结构参数

Table 1. Structural parameters of bearing

结构参数	参数数值
滚动体数量Z	19
轴承内径d/mm	130
轴承外径D/mm	200
轴承宽度B/mm	33
滚动体直径D_w/mm	22.225
节圆直径d_m/mm	165
初始接触角α⁰/（°）	30
垫片厚度h/mm	0.18
外圈沟曲率系数f_e	0.5129
内圈沟曲率系数f_i	0.5179

下载: 导出CSV

参考文献(25)

[1]	洪杰, 马艳红, 张大义. 航空燃气轮机总体结构设计与动力学分析[M]. 北京: 北京航空航天大学出版社, 2014. Hong Jie, Ma Yanhong, Zhang Dayi. Overall structural design and dynamic analysis of aviation gas turbine[M]. Beijing: Beijing University of Aeronautics & Astronautics Press, 2014. (in Chinese Hong Jie, Ma Yanhong, Zhang Dayi. Overall structural design and dynamic analysis of aviation gas turbine[M]. Beijing: Beijing University of Aeronautics & Astronautics Press, 2014. (in Chinese)
[2]	周志澜, 马纯民. 航空发动机主轴轴承失效分析与预防[M]. 北京: 科学出版社, 1998: 142-145. Zhou Zhilan. Failure analysis and prevention of aero-engine spindle bearing[M]. Beijing: Science Press, 1998: 142-145. (in Chinese Zhou Zhilan. Failure analysis and prevention of aero-engine spindle bearing[M]. Beijing: Science Press, 1998: 142-145. (in Chinese)
[3]	Hamrock B J, Anderson W J. Arched-outer-race ball-bearing analysis considering centrifugal forces, TN D-6765[R]. Cleveland, US: National Aeronautics and Space Administration, 1972.
[4]	Leblanc A, Nelias D. Ball motion and sliding friction in a four-contact-point ball bearing[J]. Journal of Tribology, 2007, 129(4): 801-808. doi: 10.1115/1.2768079
[5]	邓四二, 闫亚超, 王燕霜, 等. 弹性支承下的双半内圈角接触球轴承振动分析[J]. 航空动力学报, 2013, 28(2): 241-251. Deng Sier, Yan Yachao, Wang Yanshuang, et al. Vibration analysis of two-piece inner ring angular contact ball bearing with elastic support[J]. Journal of Aerospace Power, 2013, 28(2): 241-251. (in Chinese doi: 10.13224/j.cnki.jasp.2013.02.006 Deng Sier, Yan Yachao, Wang Yanshuang, et al. Vibration analysis of two-piece inner ring angular contact ball bearing with elastic support[J]. Journal of Aerospace Power, 2013, 28(2): 241-251. (in Chinese) doi: 10.13224/j.cnki.jasp.2013.02.006
[6]	王亚涛, 邱明, 张家铭, 等. 四点接触球轴承钢球-沟道多点接触成因分析[J]. 中国机械工程, 2023, 34(23): 2794-2804. Wang Yatao, Qiu Ming, Zhang Jiaming, et al. Cause analysis on multi-point contact between steel ball and raceway of four-point contact ball bearings[J]. China Mechanical Engineering, 2023, 34(23): 2794-2804. (in Chinese doi: 10.3969/j.issn.1004-132X.2023.23.003 Wang Yatao, Qiu Ming, Zhang Jiaming, et al. Cause analysis on multi-point contact between steel ball and raceway of four-point contact ball bearings[J]. China Mechanical Engineering, 2023, 34(23): 2794-2804. (in Chinese) doi: 10.3969/j.issn.1004-132X.2023.23.003
[7]	彭城, 曹宏瑞, 朱玉彬, 等. 三点接触球轴承打滑动力学分析与验证[J]. 机械工程学报, 2023, 59(1): 123-130. Peng Cheng, Cao Hongrui, Zhu Yubin, et al. Dynamic analysis and verification on skidding behavior of three-point contact ball bearings[J]. Journal of Mechanical Engineering, 2023, 59(1): 123-130. (in Chinese doi: 10.3901/JME.2023.01.123 Peng Cheng, Cao Hongrui, Zhu Yubin, et al. Dynamic analysis and verification on skidding behavior of three-point contact ball bearings[J]. Journal of Mechanical Engineering, 2023, 59(1): 123-130. (in Chinese) doi: 10.3901/JME.2023.01.123
[8]	Aguirrebeitia J, Abasolo M, Avilés R, et al. General static load-carrying capacity for the design and selection of four contact point slewing bearings: Finite element calculations and theoretical model validation[J]. Finite Elements in Analysis and Design, 2012, 55: 23-30. doi: 10.1016/j.finel.2012.02.002
[9]	Halpin J D, Tran A N. An analytical model of four-point contact rolling element ball bearings[J]. Journal of Tribology, 2016, 138(3): 031404. doi: 10.1115/1.4033134
[10]	Lin B, Duan M L, Okwudire C E, et al. A simplified analytical model of rolling/sliding behavior and friction in four-point-contact ball bearings and screws[C]//ASME 2017 International Mechanical Engineering Congress and Exposition, Ithaca: Journal of Tribology, 2017: 10-16.
[11]	Yao Tingqiang, Wang Lihua, Liu Xiaobao, et al. Multibody dynamics simulation of thin-walled four-point contact ball bearing with interactions of balls, ring raceways and crown-type cage[J]. Multibody System Dynamics, 2020, 48(3): 337-372. doi: 10.1007/s11044-019-09704-1
[12]	陈月, 邱明, 杜辉, 等. 机器人用四点接触球轴承旋转精度影响因素[J]. 中国机械工程, 2020, 31(14): 1678-1685, 1692. Chen Yue, Qiu Ming, Du Hui, et al. Factors influencing rotation accuracy of four-point contact ball bearings for robots[J]. China Mechanical Engineering, 2020, 31(14): 1678-1685, 1692. (in Chinese doi: 10.3969/j.issn.1004-132X.2020.14.006 Chen Yue, Qiu Ming, Du Hui, et al. Factors influencing rotation accuracy of four-point contact ball bearings for robots[J]. China Mechanical Engineering, 2020, 31(14): 1678-1685, 1692. (in Chinese) doi: 10.3969/j.issn.1004-132X.2020.14.006
[13]	唐瑞, 高利霞, 余丹, 等. 三点接触球轴承拟动力学模型分析及验证[J]. 航空动力学报, 2024, 39(8): 483-495. Tang Rui, Gao Lixia, Yu Dan, et al. Analysis and verification of the quasi-dynamic model for the three-point contact ball bearing[J]. Journal of Aerospace Power, 2024, 39(8): 483-495. (in Chinese doi: 10.13224/j.cnki.jasp.20230068 Tang Rui, Gao Lixia, Yu Dan, et al. Analysis and verification of the quasi-dynamic model for the three-point contact ball bearing[J]. Journal of Aerospace Power, 2024, 39(8): 483-495. (in Chinese) doi: 10.13224/j.cnki.jasp.20230068
[14]	俞加欣. 避免三点接触临界条件的探讨[J]. 轴承, 1993(12): 6-9, 21-39. Yu Jiaxin. Critical condition research of avioding three point contact[J]. Bearing, 1993(12): 6-9, 21-39. (in Chinese doi: 10.19533/j.issn1000-3762.1993.12.002 Yu Jiaxin. Critical condition research of avioding three point contact[J]. Bearing, 1993(12): 6-9, 21-39. (in Chinese) doi: 10.19533/j.issn1000-3762.1993.12.002
[15]	王黎钦, 崔立, 郑德志, 等. 航空发动机高速球轴承动态特性分析[J]. 航空学报, 2007, 28(6): 1461-1467. Wang Liqin, Cui Li, Zheng Dezhi, et al. Analysis on dynamic characteristics of aero-engine high-speed ball bearings[J]. Acta Aeronautica et Astronautica Sinica, 2007, 28(6): 1461-1467. (in Chinese doi: 10.3321/j.issn:1000-6893.2007.06.032 Wang Liqin, Cui Li, Zheng Dezhi, et al. Analysis on dynamic characteristics of aero-engine high-speed ball bearings[J]. Acta Aeronautica et Astronautica Sinica, 2007, 28(6): 1461-1467. (in Chinese) doi: 10.3321/j.issn:1000-6893.2007.06.032
[16]	李震, 关先磊, 钟锐, 等. 联合载荷下角接触球轴承的动态特性分析[J]. 机械工程学报, 2020, 56(17): 116-125. Li Zhen, Guan Xianlei, Zhong Rui, et al. Analysis of dynamic characteristics of angle contact bearings with combined loads[J]. Journal of Mechanical Engineering, 2020, 56(17): 116-125. (in Chinese doi: 10.3901/JME.2020.17.116 Li Zhen, Guan Xianlei, Zhong Rui, et al. Analysis of dynamic characteristics of angle contact bearings with combined loads[J]. Journal of Mechanical Engineering, 2020, 56(17): 116-125. (in Chinese) doi: 10.3901/JME.2020.17.116
[17]	刘鲁, 赵聪, 冯小川, 等. 角接触球轴承在高速大载荷工况下滑油中断耐受能力分析[J]. 航空动力学报, 2021, 36(11): 2430-2436. Liu Lu, Zhao Cong, Feng Xiaochuan, et al. Analysis of oil-off tolerance of angular contact ball bearing under condition of high speed and heavy load[J]. Journal of Aerospace Power, 2021, 36(11): 2430-2436. (in Chinese doi: 10.13224/j.cnki.jasp.20200526 Liu Lu, Zhao Cong, Feng Xiaochuan, et al. Analysis of oil-off tolerance of angular contact ball bearing under condition of high speed and heavy load[J]. Journal of Aerospace Power, 2021, 36(11): 2430-2436. (in Chinese) doi: 10.13224/j.cnki.jasp.20200526
[18]	Ma Shuaijun, He Gaobo, Yan Ke, et al. Structural optimization of ball bearings with three-point contact at high-speed[J]. International Journal of Mechanical Sciences, 2022, 229: 107494. doi: 10.1016/j.ijmecsci.2022.107494
[19]	张弛. 航空发动机轴系轴承试验器设计与系统耦合力学特性研究[D]. 哈尔滨: 哈尔滨工业大学, 2013. Zhang Chi. Desigh of aeroengine inter-bearing test rig and study on systenm coupled mechanics[D]. Harbin: Harbin Institute of Technology, 2013. (in Chinese Zhang Chi. Desigh of aeroengine inter-bearing test rig and study on systenm coupled mechanics[D]. Harbin: Harbin Institute of Technology, 2013. (in Chinese)
[20]	闫众. 基于试验器的中介球轴承可靠性试验研究[D]. 哈尔滨: 哈尔滨工业大学, 2019. Yan Zhong. The reliability test research of intermediate ball bearing based on tester[D]. Harbin: Harbin Institute of Technology, 2019. (in Chinese Yan Zhong. The reliability test research of intermediate ball bearing based on tester[D]. Harbin: Harbin Institute of Technology, 2019. (in Chinese)
[21]	Cao Hongrui, Wang Dong, Zhu Yubin, et al. Dynamic modeling and abnormal contact analysis of rolling ball bearings with double half-inner rings[J]. Mechanical Systems and Signal Processing, 2021, 147: 107075. doi: 10.1016/j.ymssp.2020.107075
[22]	余奥迪. 航空发动机主轴承疲劳寿命预测及可靠性分析[D]. 成都: 电子科技大学, 2022. Yu Aodi. Fatigue life prediction and reliability analysis of aero-engine main shaft bearings[D]. Chengdu: University of Electronic Science and Technology of China, 2022. (in Chinese Yu Aodi. Fatigue life prediction and reliability analysis of aero-engine main shaft bearings[D]. Chengdu: University of Electronic Science and Technology of China, 2022. (in Chinese)
[23]	王亚涛. 航发主轴四点接触球轴承摩擦特性研究[D]. 洛阳: 河南科技大学, 2024. Wang Yatao. Research on friction characteristics of four-point-contact ball bearings of aeroengine mainshaft[D]. Luoyang: Henan University of Science and Technology, 2024. (in Chinese Wang Yatao. Research on friction characteristics of four-point-contact ball bearings of aeroengine mainshaft[D]. Luoyang: Henan University of Science and Technology, 2024. (in Chinese)
[24]	Gupta P K. Dynamics of rolling-element bearings: part Ⅲ ball bearing analysis[J]. Journal of Lubrication Technology, 1979, 101(3): 312-318. doi: 10.1115/1.3453363
[25]	Gupta P K. Dynamics of rolling-element bearings: Part Ⅳ ball bearing analysis[J]. Journal of Lubrication Technology, 1979, 101(3): 319-326. doi: 10.1115/1.3453364
