双圆弧单排叶栅和串列叶栅流动性能的试验研究
EXPERIMENTAL INVESTIGATION ON CHARACTERISTICS OF SINGLE AND TANDEM BLADE CASCADES WITH DOUBLE-CIRCULAR ARC PROFILE
-
摘要: 本文对按照“单个的和串列的叶轮机械平面双圆弧叶型坐标的计算机程序”设计出的单排叶栅和串列叶栅,在Ma1=0.3;Re=2×105下,进行了吹风试验获得叶栅的正常特性线;即气流转角△β和叶型损失系数随气流攻角i的变化关系。从而可以清楚地看出在设计压气机叶型叶栅时采用串列叶栅具有转角大损失小的优点。Abstract: A single cascade and a tandem cascade with double-circular arc profile havebeen designed and investigated .which have same total cord, total camber, constructional inlet and exit angles, and solidity as the reference tandem compressor stator Wade of Turmo Ⅲc gas turbine engine. The inlet Mach number is 0. 3. The characteristics of both single and tandem cascades, such as the dependence of turning angle Δβ and coefficient of total pressure lossω on incidence angle i have been obtained. The experimental data are compared and analyzed.
