转子后总压旋态误差的研究
AN INVESTIGATION ON STAGNATION PRESSURE ERRORS DUE TO ROTATION STATE BEHIND A ROTOR
-
摘要: 总压测量时,测点气流的真实总压是p*(不考虑探针的干扰),而探针感受到的压力是p0转子后旋态使气流方向有大幅度变化(如图1,在近场尾迹中可达40°),因此一般p0不一定与真实压力恒等,测试系统最后得到指示压力P1工程上一般要求总压的质量平均值pm*,而在指示端得到的是指示压力的时间平均值芦pH1。Abstract: This paper proposes that the errors in stagnation pressure measurement due torotation state behind a rotor should include perception errors in addition to the weighting error and dynamic response errors. The analysis and experimental data show that the stagnation pressure in wake may be higher than that in the main flow,so the weighting error may be positive. These two conclusions are contrary to the affimation of reference [1]. This paper also puts forward various approaches to minimize the errors due to the rotation state.
