对进气道插板试验数据的一点探讨
Analysis of Distortion Test Data by Inlet Flat Baffle
-
摘要: 以实际进气道 /发动机插板逼喘试验数据为依据,对发动机进口畸变流场的试验数据进行了分析,并对进一步改进动态数据采集的设计提出了一点看法,供探讨。Abstract: In this paper,a method of installing a movable flat baffle upstream the inlet for inducing a distortion flow field is introduced.The airflow disturbance level (W) and the airflow pulsation intensity of engine intake is defined.The test data of distortion flow field at engine intake was analysed,which was obtained by inlet/engine matching test.It is showed that the distribution of dynamic pressure sensors is very important for the disturbance level (W) and the airflow pulsation intensity.And the data sampling rate and sampling time of dynamic pressure can be decreased.
-
Key words:
- inlet /
- engine /
- inlet baffle /
- distortion
