定常吹/吸气控制凸包分离的数值研究

季路成; 林峰; Marco P Schoen

定常吹/吸气控制凸包分离的数值研究

1.
中国科学院工程热物理研究所, 北京 100080
2.
Applied Research Center(ARC)Indiana Institute of Technology, Fort Wayne, IN 46803, USA
3.
Measurement and Controls Enginering Research Center(M CERC), College of Engineering, Idaho State University, Pocatello, ID 83209, USA)

基金项目: 国家自然科学基金资助(50376062)

计量
- 文章访问数: 1429
- HTML浏览量: 4
- PDF量: 360
- 被引次数: 0
出版历程
- 收稿日期: 2005-01-24
- 修回日期: 2005-10-28
- 刊出日期: 2006-02-28

Numerical Investigations of Separation Control of a Hump Model with Steady Suction and Injection

1.
Institute of Engineering Thermophysics, Chinese Academy of Sciences, Beijing100080, China
2.
Applied Research CenterARC), Indiana Institute of Technology, Fort Wayne, IN 46803, USA
3.
Measurement and Controls Enginering Research CenterMCERC), College of Engineering, Idaho State University, Pocatello, ID 83209, USA

摘要

摘要: 针对凸包流动分离主动控制开展了参数化数值研究。凸包模型为NASA设计用于流动分离主动控制的内外流通用模型。重点研究运行参数变化时定常吹/吸气影响。首先采用试验数据标定了所开发程序,然后进行了一系列参数化数值模拟。结果显示:定常吸气作用明显不同于定常吹气。对于所给定几何模型,不管吸气流量增加到多大,吸气都无法消除分离,而吹气可以做到。详细展示流动结构并讨论了流动机理。
- 航空、航天推进系统 /
- 流动控制 /
- 分离流动 /
- 凸包流动 /
- 计算流体力学
Abstract: A series of numerical parametric studies on active control of separation flow over a hump model are presented. The model is a generic model for both internal and external flow,designated by NASA for CFD validation of active separation control.The focus is on the influence of steady suction and injection when a variety of operating parameters are varied.An in-house-use CFD code is first validated against experimental data and other CFD results,followed by a series of numerical simulations.Results show that the behaviors of steady suction are significantly different from that of steady injection.At the given geometry,the suction alone cannot completely eliminate the separation bubble in the flow-field of the hump model regardless of how much suction flow rate is used,but the injection can.The detailed flow structure and mechanisms are also presented and discussed.
- aerospace propulsion system /
- flow control /
- separation flow /
- hump model /
- computational fluid dynamics

HTML

参考文献(6)

[1]	Kral L D.Active Flow Control technology[J].ASME Fluids Engineering Division Newsletter,1999; 3～6.
[2]	Gad-el-Hak M,Bushnell D M.Separation Control; Review[J].Journal of Fluid Engineering,1991,113; 5 ～ 30.
[3]	Huang L,Huang P G,LeBeau R P,Hauser T.Numerical Study of Blowing and Suction Control Mechanism on NACA0012 Airfoil[J].Journal of Aircraft,2004,41 (5);1005～1013.
[4]	Rumsey C L,Gatskiy T B,Sellers W L,Vatsax V N,Viken S A.Summary of the CFD Validation Workshop on Synthetic Jets and Turbulent Separation Control[R].AIAA 2004-2217,2nd AIAA Flow Control Conference,June 28 to July 1,Portland,OR.
[5]	Seifert A,Pack L G.Active Flow Separation Control on WallMouted Hump at High Reynolds Numbers[J].AIAA Journal,2002,40(7) ;1364～1372.
[6]	Chima R V.A k-ω Turbulence Model for Quasi-Three-Dimensional Turbomachinery Flows[R].NASA TM-107051,Jan.1996.
