直升机桨叶刚柔耦合特性及计算方法分析

韩东; 高正; 王浩文; 张虹秋

直升机桨叶刚柔耦合特性及计算方法分析

1.
南京航空航天大学直升机旋翼动力学国家级重点实验室, 江苏南京 210016
2.
中国试飞研究院, 陕西西安 710089

计量
- 文章访问数: 1565
- HTML浏览量: 14
- PDF量: 440
- 被引次数: 0
出版历程
- 收稿日期: 2005-03-29
- 修回日期: 2005-08-07
- 刊出日期: 2006-02-28

Analysis of the Computational Method and the Helicopter Blade Characteristics with Coupled Rigid and Elastic Motions

1.
National Key Laboratory of Rotorcraft Aeromechanics, Nanjing University of Aeronautics and Astronautics, Nanjing210016, China
2.
China Flight Test Establishment, Xi'an 710089, China

摘要

摘要: 为了研究桨叶刚柔耦合特性,采用中等变形梁模型处理桨叶弹性变形,分别采用小转角和有限转角两种方法处理桨叶绕铰的刚性运动。以桨叶扬起下坠碰撞问题为研究对象。计算分析表明:(1)弹性桨叶存在较明显的刚性运动和弹性变形耦合;(2)挥舞角较小时,两种处理方法计算结果一致,均与试验数据吻合较好;(3)挥舞角较大时,刚柔耦合增强,两种处理方法的计算值差别较为明显;(4)桨叶弯曲刚度对桨叶刚柔耦合特性有较明显影响,刚度越小,耦合越强;(5)桨叶如果比较柔软,小转角处理方法计算值相对有限转角处理方法,相位滞后、幅值增加均较为明显,计算桨叶动响应时需引起注意。
- 航空、航天推进系统 /
- 直升机 /
- 桨叶 /
- 刚柔耦合 /
- 小转角 /
- 有限转角
Abstract: In order to investigate the coupling characteristics between elastic deflections and rigid motions of the blades,the moderate deflection beam model was adopted to treat elastic deflections and two methods were adopted to treat rigid motions based on infinitesimal rotation and finite rotation.The impact problem of the blade droop stop was analyzed.Results show:(1) coupling of elastic deflections with rigid motions is distinctive;(2) computations of two methods are in good agreement with test data,when rotation angle is small;(3) when rotation angle is large,couplings increase distinctly and the differences between the results of the two computational methods increase;(4) the bending stiffness has evident effect on the coupling,and the coupling will increase with the decrease of bending stiffness;(5) in case of the blade is relatively soft,the calculated values of phase lag and amplitude augment based on infinitesimal rotation will exist.This phenomenon should be paid attention to,when blade dynamic response is calculated.
- aerospace propulsion system /
- helicopter /
- blade /
- coupling of elastic deflections with rigid motions /
- infinitesimal rotation /
- finite rotation

HTML

参考文献(7)

[1]	Colin R T.Helicopter Flight Dynamics Simulation with Refined Aerodynamics Modeling[D].Uninversity of Maryland;2000.
[2]	Keller J A.Analysis and Control of the Transient Aeroelastic Response of Rotors During Shipboard Engagement and Disengagement Operations[D].Pennsylvania State University;2001.
[3]	Bottasso C L,Bauchau O A.Multibody Modeling of Engage and Disengage Operations of Helicopter Rotors[J].Journal of the American Helicopter Society,2001,46(4) ;290～300.
[4]	Wang Hao-wen,Gao Zheng.Rotor Vibratory Load Prediction Based on Generalized Forces[J].Chinese Journal of Aeronautics,2004,17(1) ;28～33.
[5]	Straub F K,Sangha K B,Panda B.Advanced Finite Element Modeling of Rotor Blade Aeroelasticity[J].Journal of the American Helicopter Society,1994,39(2) ;56～68.
[6]	Keller J A.Experiment and Theoretical Correlation of Helicopter rotor Blade-Droop Stop Impacts[J].Journal of Aircraft,1999,36 (2); 443～450.
[7]	Keller J A,Smith E C.Experiment/Theoretical Correlation of Analysis for Helicopter Rotor Blade/Droop Stop Impacts[R].AIAA-97-1094,1997.
