利用三角形突片改善气膜冷却效率的数值研究

李永康; 张靖周; 姚玉

利用三角形突片改善气膜冷却效率的数值研究

1.
南京航空航天大学能源与动力学院, 江苏南京 210016
2.
中国燃气涡轮研究院, 四川成都 610500

基金项目: 航空科学基金资助(03C52019)

计量
- 文章访问数: 1789
- HTML浏览量: 299
- PDF量: 451
- 被引次数: 0
出版历程
- 收稿日期: 2004-10-28
- 修回日期: 2005-08-05
- 刊出日期: 2006-02-28

Numerical Investigation on Improvement of Film Cooling Effectiveness Using Delta-Shaped Tabs

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
China Gas Turbine Establishment, Chengdu 610500, China

摘要

摘要: 运用数值计算方法对带有平行于冷却壁面、且覆盖部分气膜孔面积的三角形突片气膜冷却结构,在不同吹风比下的流动过程和冷却效率进行了数值研究,以揭示突片对改善气膜冷却效率的影响。在突片的作用下,射流向主流的垂直穿透能力有一定程度的降低,在气膜孔下游,二次流能够更好地贴附壁面,气膜冷却效率均有不同程度的改善,而且随着突片堵塞比的提高,冷却效率的提高幅度越大,并且在高吹风比下的影响更为显著。
- 航空、航天推进系统 /
- 气膜冷却 /
- 突片 /
- 流动传热 /
- 数值计算
Abstract: The flow fields and cooling effectiveness of the film cooling from a row of cylindrical angled holes with triangular tabs are investigated numerically in several blowing ratios,to reveal the effects of tabs on the film cooling performance.The tabs are located along the upstream edge of the holes and placed parallel to the film cooling surface covering a part of the hole.The results show that the tabs improve film effectiveness due to the penetration of the film secondary flow into the cross flow is suppressed under the action of the tabs.And the film cooling effectiveness improvement is significant in the cases of higher blowing ratio and higher tab blocking ratio.
- aerospace propulsion system /
- film cooling /
- tabs /
- flow and heat transfer /
- numerical computation

HTML

参考文献(10)

[1]	葛绍岩,刘登瀛,徐靖中,等.气膜冷却[M].北京;科学出版社,1985.
[2]	Goldstein R J,Eckert E R G,Burggraf B.Effects of Hole Geometry and Desity on Three-Dimensional Film Cooling[J].International Journal of Heat and Mass Transfer,1992,17;595～607.
[3]	Schmidt D,Sen B,Bogard D.Film Cooling with Compound Angle Holes; Adiabatic Effectiveness[J].Journal of Turbomachinary,1996,118; 807～813.
[4]	Yuen C N N,Martinez-Botas R F,Whitelaw J H.Film Cooling Effectiveness Downstream of Compound and Fan-Shaped Holes[R].ASME Paper 2001 -GT-1031,2001.
[5]	朱惠人,许都纯,刘松龄,王宝珑.簸箕形排孔气膜冷却实验研究[J].航空学报,1997,18(5);535～538.ZHU Huiren,XU Duchun,LIU Songlin,WANG Baolong.Film Cooling Experimental Investigation of Row of Dust-Pan Shaped Holes[J].ACTA Aeronatuic Et Astronautic Sinica,1997,18(5);535～538.
[6]	Walters D K,Leylek J H.A Systematic Computational Methodology Applied to a Three-Dimensional Film Cooling Flowfield[J].Journal of Turbomachinery,1997,119; 777 ～785.
[7]	Zaman K B M Q.Reduction of Jet Penetration in a CrossFlow by Using Tabs[R].AIAA Paper 98-3276,1998.
[8]	Zaman K B M Q.Effect of Oscillating Tabs on a Jet-in-Crossflow[R].AIAA Paper 2003-0632,2003.
[9]	Nasir H,Acharya S,Ekkad S.Improved Film Cooling from Cylindrical Angled Holes with Triangular Tabs;Effect of Tab Orientations[J].International Journal of Heat and Fluid Flow,2003,24; 657～ 668.
[10]	王扬平,姜培学.应用分离涡模型计算斜圆柱孔气膜冷却[J].工程热物理学报,2005,26(4);668～670.WANG Yangping,JIANG Peixue.Detached Eddy Simulation of Cylindrical Hole Film Cooling[J].Journal of Engineering Thermophysics,2005,26 (4); 668 ～ 670.
