移动壁对压气机叶栅间隙流动的影响

吴艳辉; 楚武利; 刘志伟

移动壁对压气机叶栅间隙流动的影响

西北工业大学动力与能源学院, 陕西西安 710072

基金项目: 国家自然科学基金资助(50506026);航空科学基金资助(05C53016);中国博士后科学基金资助(2005037790)

计量
- 文章访问数: 2116
- HTML浏览量: 110
- PDF量: 394
- 被引次数: 0
出版历程
- 收稿日期: 2005-01-25
- 修回日期: 2005-09-26
- 刊出日期: 2006-02-28

Influence of Moving End-Wall on Tip Clearance Flow in an Axial-Flow Compressor Cascade

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 采用分区网格处理方法并发展了基于分块结构的三维N-S方程流体求解器,用以模拟压气机间隙区域复杂的流动现象。以一压气机叶栅为研究对象,计算分析了端壁静止和端壁移动情况下叶栅内部的三维流场,并考虑了间隙大小的影响。通过详细分析叶栅通道内部及尾迹区域的流动并与已有的实验结果对比分析表明,程序较好地模拟出了移动壁效应对间隙区域二次流动形成和发展的影响。数值和实验结果均表明,端壁移动情况下间隙区域的二次流动特征是刮削泄漏涡的形成和发展。
- 航空、航天推进系统 /
- 压气机叶栅 /
- 移动壁 /
- 刮削泄漏涡 /
- 间隙流动
Abstract: Blocked structure three-dimensional Navier-Stokes flow solver has beendeveloped and applied to investigate the complex flow phenomena in the tip gap of axial flow compressor cascade.Numerical analysis was carried out to investigate the influence of tip clearance on the flow-field in a compressor cascade with a moving end-wall.The calculated results were compared with the available experimental data and good agreements were achieved.Secondary traverse flow velocity vector plots show the scrapping of the tip leakage vortex from the suction surface of one blade across the blade pitch to the pressure surface of the adjacent blade.
- aerospace propulsion system /
- compressor cascade /
- moving end-wall /
- scrapped tip leakage vortex /
- tip clearance flow

HTML

参考文献(11)

[1]	Inoue M,Kuroumaru M.Structure of Tip Clearance Flow in an Isolated Axial Flow Compressor Rotor[J].ASME Journal of Turbomachinery,1989,111 (2) ; 250～256.
[2]	Inoue M,Kuroumaru M.Behavior of Tip Leakage Flow Behind an Axial Compressor Rotor[J].ASME Journal of Engineering for Gas Turbine and Power,1986,108 (1); 7 ～ 14.
[3]	Kunz R F,et al.Investigation of Tip Clearance Phenomena in an Axial Flow Compressor Cascade Using Euler and NavierStokes Procedures[J].AS M E Journal of Turbomachinery,1993,115;453～467.
[4]	Kang S,Hirsch C.Numerical Simulation of Three Dimensional Viscous Flow in a Linear Compressor Cascade with Tip Clearance[J].ASME Journal of Turbomachinery,1996,118;492～503.
[5]	Yaras M I,Sjolander S A.Effects of Simulated Rotation on Tip Leakage Flow in a Planar Cascade of Turbine Blades; Part I -Tip Gap Flow[J].ASME Journal of Turbomachinery,1992,114 (3) ;652～659.
[6]	Yaras M I,Sjolander S A.Effects of Simulated Rotation on Tip Leakage in a Planar Cascade of Turbine Blades; Part Ⅱ -Downstream Flow Field and Blade Loading[J].ASME Journal of Turbomachinery,1992,114; 660 ～ 667.
[7]	Peter L J.Influence of a Moving End Wall on the Tip Clearance Vortex in an Axial Compressor Cascade[R].AFIT/GAE/ ENY /95D-19,1995.
[8]	Mcmullan R J.Influence of Tip Clearance on the Flow Field in a Compressor Cascade with a Moving Endwall[R].AFIT/GAE/ ENY /96D-5,1996.
[9]	王正明,贾希诚,王嘉伟.不同间隙条件下的叶顶区流动[J].工程热物理学报,2003,24(2);228～230.Jia Xicheng,Wang Zhengming,Wang Jiawei.The Flow in Blade Tip Region under Different Clearance Conditions[J].Journal of Engineering Thermophysics,2003,24 (2); 228 ～230.
[10]	贾希诚,王正明,王嘉伟.叶轮机械中的泄漏流动与泄漏涡[J].工程热物理学报,2003,24(5);753～756.Jia Xicheng,Wang Zhengming,Wang Jiawei.Leakage Flow and Leakage Vortex in Turbomachinery[J].Journal of Engineering Thermophysics,2003,24 (5) ;753～756.
[11]	邓向阳,张宏武.叶顶间隙大小和壁面相对运动对低速轴流压气机孤立转子性能的影响[J].工程热物理学报,2004,25(5);773～775.Deng Xangyang,Zhang Yongwu.The Effect of Tip Clearance Gap Size and Wall Rotation on the Performance of a Low-Speed Axial Compressor Rotor[J].Journal of Engineering Thermophysics,2004,25 (5); 753～756.
