压气机转子三维流场计算中叶尖间隙网格的影响

张辉; 马宏伟; 蒋浩康

压气机转子三维流场计算中叶尖间隙网格的影响

北京航空航天大学航空发动机气动热力重点实验室, 北京 100083

基金项目: 国家自然科学基金资助(5980600150376002);航空科学基金资助(04C51030)

计量
- 文章访问数: 1615
- HTML浏览量: 2
- PDF量: 428
- 被引次数: 0
出版历程
- 收稿日期: 2004-12-20
- 修回日期: 2005-04-25
- 刊出日期: 2006-02-28

Effects of Tip Clearance Grids on the Simulations of Three-Dimensional Flow Fields in a Low Speed Compressor Rotor

National Key Laboratory on Aero-Engines, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要

摘要: 对一带叶尖间隙的低速轴流压气机转子三维流场进行了数值模拟,通过与实验结果对比,分析了叶尖网格匹配、网格质量对压气机转子三维流场计算的影响,发现网格正交性和网格疏密过渡会影响二阶计算精度的收敛,研究还显示压升特性线不能准确的反映网格数目对计算结果的影响。
- 航空、航天推进系统 /
- 压气机 /
- 转子 /
- 叶尖间隙 /
- 三维流场 /
- 网格
Abstract: The 3-D flow fields of a low-speed axial compressor rotor with a tip clearance were calculated.Compared with experimental results,effects of the tip grid-matching and the grid quality on numerical results were investigated.The result shows the requirement of the gird-matching between the tip clearance and the rotor passage for simulations of flow details in the tip clearance,and the sensitivity of the second-order difference scheme to the grid quality.In addition,it was revealed that the pressure rise characteristics did not exactly reflect the effect of grid numbers on numerical results.
- aerospace propulsion system /
- compressor /
- rotor /
- tip clearance /
- 3-D flow field /
- gird

HTML

参考文献(8)

[1]	Cumpsty N A.Compressor Aerodynamics[M].Harlow,Essex,England ; Longman Scientific & Technical,1989.
[2]	Denton J D.Loss Mechanisms in Turbomachines[R].ASME 93-GT-435.
[3]	邓向阳,张宏武,陈乃兴,等.叶顶间隙大小和壁面相对运动对低速轴流压气机孤立转子性能的影响[J].工程热物理学报,2004,125(5);773～775.Deng Xiangyang,Zhang Hongwu,Chen Naixing et al.The Effect of Tip Clearance Gap Size and Wall Rotation on the Performance of a Low-Speed Axial Compressor Rotor[J].Journal of Engineering Thermophysics,2004.125(5); 773 ～ 775.
[4]	蒋浩康,马宏伟.压气机转子三维紊流流场[J].工程热物理学报,1998,19(3);287～292.Jiang Haokang,Ma Hongwei.Three-Dimensional Turbulent Flow Field of Axial Compressor Rotor Passage[J].Journal of Engineering Thermophysics,1998,19 (3); 287 ～ 292.
[5]	Gupta A,Khalid S A.McNulty G S,et al.Prediction of Low Speed Compressor Rotor Flowfields with Large Tip Clearance[R].ASME GT2003-38637.
[6]	蒋浩康,李雨春,张洪,等.研究转子内流动的大尺寸轴流压气机实验装置和动态测量技术[J].航空动力学报,1992,7(1);1～8.Jiang Haokang,Li Yuchun,Zhang Hong,et al.A Large-Scale Axial Flow Compressor Facility and Dynamic Measurement Techniques for Rotor Flow Study[J].Journal of Aerospace Power,1992.7(1) ;1～8.
[7]	马宏伟.压气机转子内三维流场实验研究[D].北京;北京航空航天大学,1996.
[8]	马宏伟,蒋浩康,单转子压气机设计和近失速状态出口三维紊流流场[J].工程热物理学报,1997.18(2);153～158.Ma Hongwei,Jiang Haokang.Three-Dimensional Turbulent Flow Field at the Exit of an Axial Compressor Rotor Passage in both Design and Near Stall Conditions[J].Journal of Engineering Thermoph ysics,1997.18(2);153 ～ 158.
