汽轮机末级三维非定常流动数值模拟

綦蕾; 邹正平; 陆宏志; 于尔亮; 田东强; 师黎明

汽轮机末级三维非定常流动数值模拟

1.
北京航空航天大学航空发动机气动热力重点实验室, 北京 100083
2.
香港理工大学机械学系, 香港
3.
北京北重汽轮电机有限责任公司, 北京 100040

计量
- 文章访问数: 1486
- HTML浏览量: 0
- PDF量: 398
- 被引次数: 0
出版历程
- 收稿日期: 2004-12-27
- 修回日期: 2005-03-28
- 刊出日期: 2006-02-28

Numerical Simulation of the 3-D Unsteady Flow in the Steam Turbine Last Stage

1.
National Key Laboratory on Aero-Engines, Beijing University of Aeronautics and Astronautics, Beijing 100083, China
2.
Department of Mechanical Engineering, The Hong Kong Polytechnic University, Hongkong, China
3.
Beijing Beizhong Steam Turbine Generator CO.LTD, Beijing 100040, China

摘要

摘要: 采用三维粘性非定常数值模拟方法,对某汽轮机设计状态末级非定常流动进行了模拟,并对设计状态下各因素引起末级动叶表面产生非定常力的大小和作用机理进行了分析。结果表明,本文中的汽轮机末级在设计条件下,上游静叶尾缘激波和位势场对下游转子的影响比尾迹作用的影响更大,静叶尾缘激波和位势场导致下游转子叶片表面非定常力大小呈周期性变化;此外上游静子尾迹以及动叶尾缘出口膨胀波等也是产生转子叶片表面非定常力的因素。
- 航空、航天推进系统 /
- 汽轮机末级 /
- 透平 /
- 非定常流 /
- 数值模拟
Abstract: The unsteady flow of the steam turbine at design state was studied by the method of numerical simulation of 3-D viscous flow,and the analyses of unsteady force on the blade surface and the mechanism of action were carried out.The result indicates that at typical design operating conditions in the last stage of the steam turbine investigated here,shock and potential field interaction from upstream blade row is an order of magnitude greater than wake interaction.The shock and potential field interaction effects cause a periodic increase in the strength of the unsteady force acting on the downstream rotor blade surface.In addition,the wake interaction of upstream blade row and the expansion wave at rotor exit also cause an unsteady force acting on the downstream rotor blade surface.
- aerospace propulsion system /
- the last stage of steam turbine /
- turbine /
- unsteady flow /
- numerical simulation

HTML

参考文献(5)

[1]	陈懋章.风扇/压气机技术发展和对今后工作的建议[J].航空动力学报,2002,17(1);1～15.CHEN Mao-zhang.Development of Fan/Compressor Techniques and Suggestions on Further Researches[J].Journal of Aerospace Power,2002,17 (1); 1 ～ 15.
[2]	Dring R P,Joslyn H D,Hardin L W,Wagner J H.Turbine Rotor-Stator Interaction[R].ASME 82-GT-3,1982.
[3]	Dénos R,Arts T,Paniagua G,Michelassi V,Martelli F.Investigation of the Unsteady Rotor Aerodynamics in a Transonic Turbine Stage[R].ASME 2000-GT 0435,2000.
[4]	Miller R J,Moss R W,Ainsworth R W.Wake,Shock and Potential Field Interactions in a 1.5 Stage Turbine;Part Ⅰ ;Vane-Rotor and Rotor-Vane Interaction[R].ASME 2002-GT-30435,2000.
[5]	Hodson H P,Dawes W N.On the Interpretation of Measured Profile Losser in Unsteady Wake-TurbineBlade Interaction Studies[R].ASME 96 -GT-494,1996.
