带摩擦阻尼装置系统振动响应分析方法研究

漆文凯; 高德平

带摩擦阻尼装置系统振动响应分析方法研究

南京航空航天大学能源与动力学院, 江苏南京 210016

计量
- 文章访问数: 1583
- HTML浏览量: 142
- PDF量: 432
- 被引次数: 0
出版历程
- 收稿日期: 2005-06-08
- 修回日期: 2005-10-25
- 刊出日期: 2006-02-28

Study of Vibration Response Analysis Method for the Dry Friction Damping Systems

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 引入整体-局部一体化滑动模型,提出了带摩擦阻尼装置平板叶片的振动响应分析方法,通过与实验结果对比,验证了分析方法的有效性;定义了无量纲正压力,通过不同无量纲正压力下平板叶片的振动响应分析,获得了振动响应与无量纲正压力的关系曲线。计算结果表明:在局部滑动阶段摩擦阻尼对系统振动的抑制仍然有明显的效果,因此在摩擦阻尼减振分析中,引入局部滑动模型具有重要意义,并可通过无量纲正压力对阻尼器的参数进行优化,使系统在共振时的响应达到最小。
- 航空、航天推进系统 /
- 干摩擦阻尼 /
- 局部滑动 /
- 整体滑动 /
- 振动响应分析
Abstract: The macro-micro slip model was used to analyze vibration response of plate blades with a dry friction damping.Compared to the experimental results,the analytical method was proved to be feasible.Non-dimensional normal force was defined,and by the use of it,the relationship between the vibration responses and non-dimensional normal force of the plate blades with a dry friction damper were obtained.The calculation results indicate that in the micro-slip stage,the friction damper can markedly reduce the responses of the vibration system,so that the introduction of micro-slip model is very important,and the non-dimensional normal force can be used as a design variable of dry friction dampers to optimize parameters of damper making the response of a vibration system to be minimum while resonance occurs.
- aerospace propulsion system /
- dry friction damping /
- micro-slip /
- macro-slip /
- vibration response analysis

HTML

参考文献(11)

[1]	Menq C H,Griffin J H,Beilak J.The Influence of a Variable Normal Load on the Forced Vibration of a Frictionally Damped Structure[J].Transactions of the ASME,Journal of Engineering for Gas Turbines and Power,1986,108;300～305.
[2]	Bazan E,Beilak J,Griffin J H.An Efficient Method for Predicting the yibratory Response of Linear Structures with Friction Interfaces[J].Transactions of the ASME,Journal of Engineering for Gas Turbines and Power,1986,108;633 ～640.
[3]	Cameron T M,Griffin J H.A New Method for Optimizing Friction Damping in Randomly Excited Systems[R].ASME Gas Turbine Conference and Exhibition 1989,89 -GE-108,1989.
[4]	Cameron T M,Griffin J H.An Alternating Frequency/Time Domain Method for Calculating the Steady State Response of Nonlinear Dynamic Systems[J].Transactions of the ASME,Journal of Applied Mechanics,1989,56;149 ～ 154.
[5]	Menq C H,Griffin J H.Friction Damping of Circular Motion and its Implications to Vibration Control[J].Transactions of the ASME,Journal of Vibration and Acoustics,1991,113;225～229
[6]	Menq C H,Chidamparam P,Griffin J H.Friction Damping of Two Dimensional Motion and Its Application in Vibration Control[J].Journal of Sound and Vibration,1991,144 (3);427～447.
[7]	Wang J H,Chen W K.Investigation of the Vibration of a Blade with Friction Damper by HBM[J].Transaction of the ASME,Journal of Engineering for Gas Turbines and Power,1993,115;294～299.
[8]	Menq C H,Beilak J,Griffin J H.The Influence of Microslip on Vibratory Response,Part Ⅰ ;A New microslip model[J].Journal of Sound and Vibration,1986,107(2);279～293.
[9]	Menq C H,Beilak J,Griffin J H.The Influence of Microslip on Vibratory Response,Part Ⅱ; A Comparison with Experimental Results[J].Journal of Sound and Vibration,1986,107(2);295～307.
[10]	郝燕平,朱梓根.带摩擦阻尼的叶片响应求解方法[J].航空学报,2001,22(5);411～414.Hao Yanping,Zhu Zigen.New Method to Resolve Vibratory Response of Blades with Friction Damping[J].Acta Aeronautica et Astronautica Sinica,2001,22 (5) ;411～414.
[11]	白鸿柏,黄协清.干摩擦振动系统响应计算方法研究综述[J].力学进展,2001,31(4);527～534.Bai Hongbai,Huang Xieqing.An Overview on Study of Methods of Response Computation for the Dry Frictionally Damped Vibration Systems[J].Advances in Mechanics,2001,31 (4); 527～ 534.
