凸肩结构对叶片的干摩擦减振研究——理论方法

Investigation of the Vibration Control by Frictional Constraints between Blade Shrouds-Theoretical Method

1.
Department of Automobile Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100083, China
2.
School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要: 提出了一套求解带凸肩结构叶片非线性响应的时频转换方法。该方法应用数值轨迹跟踪法计算凸肩复杂接触面内的非线性摩擦力,并将其与频域内的谐波平衡法、动柔度法相结合求解带凸肩结构叶片的非线性响应,方法能够考虑叶片高阶振型以及响应高次谐波的影响,为带凸肩叶片的设计及故障诊断奠定了理论基础。
- 航空、航天推进系统 /
- 干摩擦 /
- 凸肩 /
- 非线性振动 /
- 叶片
Abstract: A new approach was developed to solve the nonlinear responses of the blades with shrouds.Transforming the calculation between frequency domain and time domain was necessary.The nonlinear friction forces were calculated between complicated friction interfaces of the shrouds by tracing the trajectory of the contact point.This numerical method was combined with the harmonic balance method and the dynamic compliance method to solve the nonlinear responses of the blades.The effects of blade high order vibration modes and the high harmonic components of the blade response were taken into account.This theoretical method can be applied to design and fault diagnosis of the blades with shrouds.
- aerospace propulsion system /
- dry friction /
- shroud /
- nonlinear vibration /
- blade

[1]	任勇生,朱德懋.带凸肩叶片的稳态响应计算及其阻尼减振分析[J].振动工程学报,1994,172(2);103～111.Ren Yongsheng,Zhu Demao.Steadystate Response Caculation and Damping Vibration Analysis of Shrouded Blades[J].Journal of Vibration Engineering,1994,172 (2); 103 ～ 111.
[2]	Meng C H,Griffin J H,Bielak J.The Forced Response of Shrouded Fan Stages[J].ASME Journal of Vibration,Acoustics,Stress,and Reliability in Design,1986,108; 50～55.
[3]	Yang B D,Meng C H.Modeling of Friction Contact and Its Application to the Design of Shroud Contact[J].Transactions of ASME Journal of Engineering for Gas Turbines and Power,1997,119; 958～963.
[4]	Yang B D,Chen J J,Meng C H.Prediction of Resonant Response of Shrouded Blades with Three-Dimensional Shroud Constraint[J].Transactions of ASME Journal of Engineering for Gas Turbines and Power,1999,121; 523～529.
[5]	Meng C H,Chidamparam P.Friction Damping of Two-Dimentional Motion and Application in Vibration Control[J].Journal of sound and vibration,1991,144..427～447.
[6]	单颖春.叶轮机械叶片干摩擦减振研究[D].北京;北京航空航天大学,2002.
