凸肩结构对叶片的干摩擦减振研究——规律分析

Investigation of the Vibration Control by Frictional Constraints Between Blade Shrouds-Rule Analysis

1.
Department of Automobile Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100083, China
2.
School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要: 针对带凸肩的平板叶片,对凸肩阻尼结构的减振规律进行了系统的研究。获得了凸肩接触面初始正压力、接触角度、接触刚度、摩擦系数等多种参数对叶片非线性响应的影响规律。此外,研究了某航空发动机带凸肩风扇叶片的振动响应,分析了凸肩结构对其一阶弯曲振型及某高阶振型的减振效果,确定了该叶片发生疲劳断裂的原因。本文工作对带凸肩结构叶片的设计、排故具有指导意义。
- 航空、航天推进系统 /
- 干摩擦 /
- 凸肩 /
- 非线性振动 /
- 叶片
Abstract: The performance of shroud damper was investigated systematically by researching the nonlinear responses of plate blades with shrouds.The influences of many contact parameters such as initial normal force,contact angle,contact stiffness and coefficient of friction were obtained.Furthermore the vibration responses of an aero-engine fan blade were investigated.The effects of shroud on the first bending mode and a higher mode of the fan blade were analyzed,and the reason of blade fracture due to fatigue was determined.The results can be used to the design and the fault diagnosis of blades with shrouds.
- aerospace propulsion system /
- dry friction /
- shroud /
- nonlinear vibration /
- blade

[1]	任勇生,朱德懋.带凸肩叶片的稳态响应计算及其阻尼减振分析[J].振动工程学报,1994,172(2);103～111.Ren Yongsheng,Zhu Demao.Steadystate Response Caculation and Damping Vibration Analysis of Shrouded Blades[J].Journal of Vibration Engineering,1994,172 (2); 103 ～ 111.
[2]	Meng C H,Griffin J H,Bielak J.The Forced Response of Shrouded Fan Stages[J].ASME Journal of Vibration,Acoustics,Stress,and Reliability in Design,1986,108 ;50～55.
[3]	Yang B D,Meng C H.Modeling of Friction Contact and Its Application to the Design of Shroud Contact[J].Transactions of ASME Journal of Engineering for Gas Turbines and Power,1997,119;958～963.
[4]	Yang B D,Chen J J,Meng C H.Prediction of Resonant Response of Shrouded Blades with Three-Dimensional Shroud Constraint[J].Transactions of ASME Journal of Engineering for Gas Turbines and Power,1999,121;523～529.
[5]	单颖春,朱梓根,刘献栋.凸肩结构对叶片的干摩擦减振研究--理论方法[J].航空动力学报,2006,21(1);168～173.Shan Yingchun,Zhu Zigen,Liu Xiandong.Investigation of the Vibration Control by Frictional Constraints between Blade Shrouds Theoretical Method[J].Journal of Aerospace and Power,21 (1) ;168～173.
[6]	单颖春.叶轮机械叶片干摩擦减振研究[D].北京;北京航空航天大学,2002.
