高压高剪切率下润滑剂剪切弹性模量的确定

王燕霜; 杨伯原; 王黎钦

高压高剪切率下润滑剂剪切弹性模量的确定

1.
哈尔滨工业大学机电工程学院, 黑龙江哈尔滨 150001
2.
河南科技大学 , 河南洛阳 471039

基金项目: 国家“十五”重大科技攻关项目(HK-2002-043/6);河南科技大学青年基金资助(2003QN05)

计量
- 文章访问数: 1467
- HTML浏览量: 18
- PDF量: 387
- 被引次数: 0
出版历程
- 收稿日期: 2005-01-18
- 修回日期: 2005-08-22
- 刊出日期: 2006-02-28

Determination of Lubricant Elastic Shear Modulus under Conditions of High Pressure and High Shear Rates

1.
School of Mechanoelectrical Engineering, Harbin Institute of Technology, Harbin 150001, China
2.
Henan University of Science and Technology, Luoyang 471039, China

摘要

摘要: 在自行研制的球盘式拖动力试验台上,测得了HKD-1型航空润滑油的拖动力;给出了高压高剪切率下滚子-润滑膜系统有效剪切弹性模量的计算公式;推导出了系统有效剪切弹性模量与润滑剂剪切弹性模量之间的关系式;以HKD-1型航空润滑油为例,计算了多种工况条件下系统有效剪切弹性模量及润滑剂本身的剪切弹性模量。结果表明:系统有效剪切弹性模量和润滑剂剪切弹性模量随压力的增大而增大,随入口油温和滚动速度的增大而减小;压力越大,入口油温和滚动速度越小,滚子的柔量对剪切变形的贡献越大。
- 航空、航天推进系统 /
- 润滑剂 /
- 流变参数 /
- 剪切弹性模量 /
- 高剪切应变率
Abstract: Traction coefficients of the new aviation lubrication oil were measured on a self-made test rig.The formula for calculating the elastic shear modulus of rollers with lubricant under conditions of high pressure and high shear rates was presented.The expressions relating effective elastic shear modulus of rollers with lubricant to the lubricant elastic shear modulus were derived.Using the new aviation lubrication oil as an example,the effective elastic shear modulus were calculated in various operating conditions.The results show that both the elastic shear modulus and the lubricant elastic shear modulus increase with the increase of pressure,and the higher the pressure and the lower the temperature and rolling speed,the greater the effect of the tangential compliance on shear deformation will be.
- aerospace propulsion system /
- lubricant /
- rheological parameters /
- elastic shear modulus /
- high shear rates

HTML

参考文献(12)

[1]	Barlow A J,Harrison G,Irving J B,et al.The Effect of Pressure on the Viscoelastic Properties of Liquids[J].Proc Roy Soc,Series A; Mathematical and Physical Sciences,1972,327 ;403.
[2]	Bair S,Winer W O.Some Observations in High Pressure Rheology of Lubricants[J].Trans ASME J Lubric Technol,1982,104(3) ;357～364.
[3]	Olver A V,Spikes H A.Prediction of Traction in Elastohydrodynamic Lubrication[J].Proc Instn Mech Engrs,Part J;Journal of Engineering Tribology,1998,212 (5); 321 ～ 332.
[4]	Tomoaki M,Tatsuo K.Estimation of Traction Properties Based on a Nonlinear Viscoelastic Model[J].Trans ASME,J Tribology,1999,121 (2); 286～293.
[5]	Fang N,Chang L,Johnson G J,et al.An Experimental/Theoretical Approach to Modeling the Viscous Behaviour of Liquid Lubricants in Elastohydrodynamic Lubrication Contacts[J].Proc Instn Mech Engrs,Part J; Journal of Engineering Tribology,2001,215(4) ; 311 ～318.
[6]	Bercea Maria,Bercea Ioan.Polyethylene as an Additive for Mineral Oils-Part Ⅱ ;EHL Traction behavior[J].STLE,Tribology Transaction,2002,45 (2); 145 ～ 152.
[7]	王燕霜,杨伯原,王黎钦,等.弹塑性流变模型在脂润滑特性分析中的应用[J].摩擦学学报,2005,25(2);159～163.Wang yanshuang,Yang boyuan,Wang Liqin,et al.Application of Elastic/Plastic Rheological Model in Characteristics Analysis of Elastohydrodynamic Lubrication of Grease[J].Tribology,2005,25(2) ;159～163.
[8]	Fang N,Chang L,Webster M N,et al.A Non-Averaging Method of Determining the Rheological Properties of Traction Fluids[J].Tribology International,2000,33 (11); 751 ～ 760.
[9]	王燕霜,杨伯原,王黎钦,等.4106航空润滑油拖动特性研究[J].摩擦学学报,2004,24(2);156～159.Wang yanshuang,Yang boyuan,Wang Liqin,et al.Traction Behavior of 4106 Aviation Lubricating Oil[J].Tribology,2004,24(2); 156～ 159.
[10]	Johnson K L,Tevaarwerk J L.Shear Behavior of Elastohy Drodynamic Oil Films[J].Proc Roy Soc Land,Series A;Mathematical and Physical Sciences,1977,356 ; 215～236.
[11]	Gupta P K,Cheng H S,Zhu D,et al.Viscoelastic Effects in Mil-L-7808-Type Lubricant,Part Ⅰ ;Analytical Formulation[J].STLE,Tribology Transaction,1992,35 (2); 269 ～274.
[12]	Johnson K L.Contact mechanics[M].England;Cambridge University Press,1985.
