涡轮典型部件冷热态尺寸换算方法

Dimension Conversion from Hot State to Cold State of the Turbine Components

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要: 涡轮叶尖间隙影响着发动机的性能,涡轮典型部件的冷热态尺寸换算是间隙设计的重要内容。介绍了应用优化设计将涡轮典型部件热态尺寸换算到冷态尺寸的方法,应用此方法对某型涡轮叶片进行分析,比较了优化算法与简化算法的结果,表明优化算法的结果是合理的,此方法是可行的。同时将其应用于某涡轮盘的冷、热态尺寸换算,从而成功地解决了涡轮典型部件冷、热态尺寸换算问题。
- 航空、航天推进系统 /
- 涡轮 /
- 尺寸换算 /
- 优化设计
Abstract: Tip clearance of the turbine plays an important role on the aeroengine performance.Dimension conversion from hot state to cold state of the turbine components is an important content of tip clearance research.In this paper,dimension conversion method using design optimization was introduced.Based on this method,a blade was analyzed.Compared with simplified method,the result is reasonable and feasible.A turbine disc was also successfully calculated with the design optimization method.Thus,the problem of dimension conversion was solved.
- aerospace propulsion system /
- turbine /
- dimension conversion /
- design optimization

[1]	航空发动机手册总编委会.航空发动机设计手册[M].第10册,涡轮,北京;航空工业出版社,1999.
[2]	吕文林.航空发动机强度计算[M].北京;国防工业出版社,1999.
[3]	王宝官.叶尖间隙随飞行状态变化的分析[R].中国工程热物理学会,传质传热学术分会,论文编号983076,1998.
[4]	朱伯芳.有限单元法原理与应用[M].北京;中国水利水电工出版社,1998.
[5]	牛冬生.涡轮叶尖间隙数值分析和冷热态尺寸换算方法研究[D].南京;南京航空航天大学,2004.
[6]	Long C A,Owen J M.The Effect of Inlet Conditions on Heat Transfer in a Rotating Cavity With a Radial Outflow of Fluid[R].ASME 86-GT-95.
