传感器故障下的航空发动机机载自适应模型重构

袁春飞; 姚华

传感器故障下的航空发动机机载自适应模型重构

袁春飞,
姚华

中国一航动力控制系统研究所, 江苏无锡 214063

基金项目: 江苏省博士后科研资助计划项目

计量
- 文章访问数: 2129
- HTML浏览量: 549
- PDF量: 458
- 被引次数: 0
出版历程
- 收稿日期: 2005-03-28
- 修回日期: 2005-08-08
- 刊出日期: 2006-02-28

Aero-Engine Adaptive Model Re-Construction under Sensor Failure

Aviation Motor Control System Institute, China Aviation Industry Corporation Ⅰ, Wuxi 214063, China

摘要

摘要: 利用航空发动机测量参数偏离正常工作情况下的变化量,可以估计发动机的非额定工作状况,并以此对机载模型进行校正,使其与真实发动机工作状况保持一致。建立了包含发动机性能蜕化因素的状态变量模型并对其进行了增广,设计了卡尔曼滤波器,根据可测输出偏离量对发动机性能蜕化值进行了估计,并将性能蜕化值用于修正发动机不可测输出参数。考虑了当某一传感器发生故障后,利用一簇卡尔曼滤波器对发生故障的传感器进行诊断并隔离,并依据剩余非故障传感器的信息对自适应模型进行重构。仿真结果表明,重构的自适应模型能够满足精度及实时性要求。
- 航空、航天推进系统 /
- 航空发动机 /
- 自适应模型 /
- 卡尔曼滤波器 /
- 状态变量模型 /
- 故障诊断
Abstract: The measured parameter deviations from nominal values can be used to predict the deterioration level of an aero-engine.A state variable model,which considered the deterioration factors,was developed.These deterioration factors were then treated as augmented states of the state variable model,thus they could be predicted by the Kalman filter based on sensed parameter deviations.If there was a sensor failure,the prediction results might not be appropriate.So a series of Kalman filters were designed as a diagnostic method to search the failed sensor.The adaptive model could be re-constructed once the failed sensor was found out.The immeasurable output parameters were trimmed by the predicted deteriorations.Adaptive performance of the re-constructed adaptive model were presented and compared with the model which had no sensor failures.The re-constructed adaptive model is shown to be able to well match the actual engine.
- aerospace propulsion system /
- aero-engine /
- adaptive model /
- Kalman filter /
- state variable model /
- fault diagnosis

HTML

参考文献(13)

[1]	Luppold R H,Roman J R,Gallops G W,Kerr L J.Estimating in-Flight Performance Variations Using Kalman Filter Concepts[R].AIAA-89-2584,AIAA/SAE/ASME/ASEE 25th Joint Propulsion Conference,July 10-12 1989,Monterey,CA.
[2]	Martin D Espana.On the Estimation Algorithm for Adaptive Performance Optimization of turbine engines[R].AIAA-93-1823,NASA TM-4551.
[3]	Gilyard G,Orme J.Subsonic Flight Test Evaluation of a Performance Seeking Control Algorithm on an F-15 Airplane[R].AIAA 92-3743,AIAA/SAE/ASME/ASEE 28th Joint Propulsion Conference and Exhibit,July 6-8,1992/Nashville,TN.
[4]	Maine T,Gilyard G,Lambert H.A Preliminary Evaluation of a F100 Engine Parameter Estimation Process Using Flight Data[R].AIAA-90-1921,AIAA/SAE/ASME/ASEE 26th Joint Propulsion Conference,July 16-18,1990/Orlando,FL.
[5]	Lambert H.A Simulation Study of Turbofan Engine Deterioration Estimation Using Kalman Filter Techniques[R].NASA-TM-104233.
[6]	李松林,孙健国,黄金泉,等.涡扇发动机机载自适应建模技术研究[J].航空动力学报,1997,13(3);315～318.Li Songlin,Sun Jianguo,Huang Jinquan,et al.An in-Flight Adaptive Model of Turbofan[J].Journal of Aerospace Power,1997,13(3);315～318.
[7]	王信德,孙健国,李松林,等.神经网络在发动机自适应建模中的应用研究[J].航空动力学报,2003,18(6);845～849.Wang Xinde,Sun Jianguo,Li Songlin,et al.Application of Neural Networks to Aeroengine Adaptive Modeling[J].Journal of Aerospace Power,2003,18(6) ;845～849.
[8]	Klaus Lietzau,Andreas Kreiner.Model Based Control Concepts for Jet Engines[R].Proceedings of ASME TURBO EXPO 2001,June 4-7,2001,New Orleans,Louisiana,USA.
[9]	Takahisa Kobayashi,Donald L Simon.Application of a Bank of Kalman Filters for Aircraft Engine Fault Diagnostics[R].NASA/TM-2003-212526.
[10]	樊思齐,徐芸华.航空推进系统控制[M].陕西西安;西北工业大学出版社,1995.
[11]	孙健国.现代航空动力装置控制[M].北京;航空工业出版社,2001.
[12]	冯正平,孙健国,黄金泉,等.一种建立航空发动机状态变量模型的新方法[J].航空动力学报,1998,13(4);435～438.Feng Zhengping,Sun Jianguo,Huang Jinquan,et al.A New Method for Establishing a State Variable Model of Aeroengine[J].Journal of Aerospace Power,1998,13 (4); 435 ～438.
[13]	胡昌华,许化龙控制系统故障诊断与容错控制的分析和设计[M].北京;国防工业出版社,2000.
