自耦合射流对平行主射流的矢量偏转PIV实验

李念; 张堃元; 徐惊雷; 沙江

自耦合射流对平行主射流的矢量偏转PIV实验

南京航空航天大学能源与动力学院, 江苏南京 210016

基金项目: 国家自然科学基金(10072027)

计量
- 文章访问数: 1616
- HTML浏览量: 146
- PDF量: 472
- 被引次数: 0
出版历程
- 收稿日期: 2005-09-08
- 修回日期: 2005-12-20
- 刊出日期: 2006-08-28

Experimental investigation of primary flow vectoring using parallel self-coupling jets

College of Energy and Power, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 为研究不同激励信号下自耦合射流对主射流的矢量偏转的影响,采用二者平行布局的方式,利用压电陶瓷单缝激励器出口两侧形成的低压区的卷吸作用,使主射流发生了明显地矢量偏转。PIV实验表明,当激励信号f=400 Hz时,自耦合射流的动量通量达到最大,主射流的对环境气体的卷吸能力最强,其边界也达到了最宽;而当激励信号f=500 Hz时,激励器出口缝处表现出最强的卷吸作用,并使流速2.6 m/s的主射流发生了最大48°的矢量偏转。
- 航空、航天推进系统 /
- PIV粒子图像测速仪 /
- 自耦合射流 /
- 射流矢量偏转
Abstract: In order to investigate the influence of self-coupling jet on the vectoring of the primary jet,parallel jets arrangement were adopted.The self-coupling jet exciter is parallel to the primary jet and the formation of a low-pressure region between the jets results in a deflection of the primary jet towards the exciting jet.The PIV experimental study shows that for f=400 Hz,the momentum flux of the self-coupling jet achieves its maximum value,while the boundary of the primary jet reaches its maximum width due to the strongest suction ability to the environmental gas.However,the experiment indicates that for f=500 Hz,due to the self-coupling jet exciting,the maximum 48° vectoring of the primary jet with a flow speed of 2.6 m/s achieves.
- aerospace propulsion system /
- PIV /
- self-coupling jet /
- self-coupling jet exciter

HTML

参考文献(10)

[1]	Kral L D.Active flow control technology[R].ASME Paper No.2001-18196.
[2]	Michael Amitay,Smith B L,Glezer Ari.Aerodynamic flow control using synthetic jet technology[R].AIAA 98-0208.
[3]	Smith B L,Glezer Ari.The formation and evolution of synthetic jets[J].Physics of Fluids,1998,10(9):2281-2297.
[4]	Smith B L,Gelzer Ari.Jet vectoring using synthetic jets[J].J.Fluid Mech,2002,458:1-34.
[5]	Yao Chungsheng,Chen Fangjenq,Dan Neuhart.Synthetic jet flow field database for CFD validation[R].AIAA 2004-2218.
[6]	罗小兵,李志信,过增元.合成喷形成的机理分析[J].清华大学学报,2000,40(12):86-89.LUO Xiaobing,LI Zhixin,Guo Zengyuan.Analysis of the mechanism of synthetic jet formation[J].J.Tsinghua Univ.(Sci&Tech),2000,40(12):86-89.
[7]	罗小兵,李志信,过增元,等.压电驱动合成喷的设计及分析[J].功能材料与器件学报,2001,7(2):116-120.LUO Xiaobing,LI Zhixin,Guo Zengyuan,et al.Design and analysis of synthetic jet actuated by piezoelectric actuator[J].Journal of Functional Materials and Devices,2001,7(2):116-120.
[8]	罗振兵,夏智勋,胡建新,等.合成射流流场数值模拟及激励器参数分析[J].推进技术,2004,25(3):199-205.LUO Zhengbing,XIA Zhixun,HU Jianxin,et al.Numerical simulation of synthetic jet flow field and parameter analysis of actuator[J].Journal of Propulsion Technolohy,2004,25(3):199-205.
[9]	罗振兵,朱伯鹏,夏智勋,等.合成射流激励器对射流矢量的影响[J].推进技术,2004,25(5):405-410.LUO Zhengbing,ZHU Bopeng,XIA Zhixun,et al.Jet vectoring using synthetic jet actuators[J].Journal of Propulsion Technolohy,2004,25(5):405-410.
[10]	李念,张堃元,徐惊雷.自耦合射流对平主行主射流的矢量偏转实验研究[J].推进技术,2005,26(3):248-251.Li Nian,ZHANG Kunyuan,XU Jinglei.Experimental investigation of primary flow vectoring using parallel synthetic jets[J].Journal of Propulsion Technology,2005,26(3):248-251.
