上游叶片尾迹对转子叶片非定常表面压力频谱特性影响的研究

王英锋; 胡骏; 罗标能; 李传鹏

上游叶片尾迹对转子叶片非定常表面压力频谱特性影响的研究

南京航空航天大学能源与动力学院, 江苏南京 210016

计量
- 文章访问数: 1786
- HTML浏览量: 155
- PDF量: 491
- 被引次数: 0
出版历程
- 收稿日期: 2005-07-05
- 修回日期: 2006-01-10
- 刊出日期: 2006-08-28

Effects of the up-stream blade wakes on the spectrum of rotor blade unsteady surface pressure

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 为了研究上游叶片尾迹对轴流压气机转子叶片非定常表面压力的影响,采用在叶片表面埋设微型压力传感器的方法,测量了一个单级低速轴流压气机转子叶片的非定常压力分布。对转子叶片非定常压力分布的分析显示:转子叶片压力面非定常表面压力主要受上游叶片尾迹影响,其主导频率为上游叶片尾迹频率及其倍频,压力波动幅度随上游叶片尾迹的衰减而沿流向减弱。转子叶片吸力面非定常压力受叶片附面层和上游叶片尾迹共同影响,其主导频率为上游叶片尾迹频率及其倍频,但是在吸力面前部气流加速区压力波动幅度沿流向增大,而在吸力面后部气流减速区压力波动幅度沿流向减小。在存在尾缘分离的情况下,在分离区附近产生较大压力波动。尾缘气流分离产生的压力波动频谱中含有上游叶片尾迹频率及其倍频的分量,但其频谱可能比较复杂,并非单一地受上游叶片尾迹影响。
- 航空、航天推进系统 /
- 叶轮机械 /
- 转静干涉 /
- 动态测量 /
- 频谱
Abstract: The unsteady surface pressures on the rotor blades of a single-stage low-speed axial compressor were measured by means of mounting micro-sensors on the surface the blades.The effects of up-stream blade wakes on the spectrum of rotor blades unsteady surface pressure were analyzed.On the rotor blade pressure surface,the dominant frequencies of unsteady surface pressure are the up-stream blade wake passing frequency and its harmonics,and the amplitudes of pressure fluctuations decrease from leading edge to trailing edge.However,on the blade suction side from leading edge to trailing edge,the amplitudes of pressure fluctuations increase at the fore part where flow accelerates and decrease at the rare part where flow decelerates.Flow separation produces pressure fluctuations of large amplitudes,possibly with the dominant frequencies differ from up-stream blade wake passing frequency and its harmonics.
- aerospace propulsion system /
- turbomachinery /
- blade row interactions /
- dynamic measurements /
- frequency spectrum

HTML

参考文献(13)

[1]	季路成,周盛.转/静干涉效应纳入设计体系的途径探索[J].工程热物理学报,1999,20(5):580-583.Ji Lucheng,Zhou Sheng.Exploration on the ways to include rotor/stator interaction effects into design system[J].Journal of Engineering Thermophysics,1999,20(5):580-583.
[2]	候安平,周盛.轴流式叶轮机时序效应的机理探讨[J].航空动力学报,2003,18(1):70-75.Hou Anping,Zhou Sheng.Probe into the mechanism of clocking effect in turbomachinery[J].Journal of Aerospace Power,2003,18(1):70-75.
[3]	周盛,侯安平,弓志强,等.关于轴流压气机的非定常两代流型[J].航空学报,2005,26(1):1-7.Zhou Sheng,Hou Anping,Gong Zhiqiang,et al.Two generations of unsteady flow type for axial comperssor[J].Acta Aeronautica et Astronautica Sinica,2005,26(1):1-7.
[4]	罗俊,李晓东.转子/静子干涉气动声学反问题研究[J].航空动力学报,2001,16(3):279-282.Luo Jun,Li Xiaodong.An inverse aeroacoustic problem on rotor stator interaction[J].Journal of Aerospace Power,2001,16(3):279-282.
[5]	郭恩民,周盛,陆亚钧.叶片排干涉对叶片颤振和强迫相应影响的研究[J].航空学报,1999,20(4):343-347.Guo Enmin,Zhou Sheng,Lu Yajun.Investigation on blade row interaction effect on flutter and forced response[J].Acta Aeronautica et Astronautica Sinica,1999,20(4):344-347.
[6]	胡骏,汤国才,于再.动叶尾迹对静子非定常气动性能影响的研究[J].航空动力学报,1999,14(4):387-392.Hu Jun,Tang Guocai.An experimental investigation on compressor rotor-stator interaction[J].Journal of Aerospace Power,1999,14(4):387-392.
[7]	Hsu S T,Wo A M.Reduction of unsteady blade loading by beneficial use of vortical and potential disturbances in an axial compressor with rotor clocking[J].ASME Journal of Turbomachinery,1998,120:705-713.
[8]	Durali M,Kerrebrock J L.Stator performance and unsteady loading in transonic compressor stages[J].ASME Journal of Turbomachinery,1998,120:224-232.
[9]	Mailach R,Vogeler K.Aerodynamic blade row interactions in an axial compressor-Part Ⅰ:Unsteady boundary layer development[J].ASME Journal of Turbomachinery,2004,126:35-44.
[10]	Mailach R,Vogeler K.Aerodynamic blade row interactions in an axial compressor-Part Ⅱ:Unsteady profile pressure distribution and blade forces[J].ASME Journal of Turbomachinery,2004,126:34-51.
[11]	Falk E A.An experimental investigation of aerodynamic forcing in the f109 turbofan engine compressor[D].Indiana:Department of Aerospace and Mechanical Engineering of the University of Notre Dame,2000.
[12]	王英锋,胡骏,李传鹏,等.上游转子对下游静子叶片气动力的影响[A].中国工程热物理学会流体机械学术会议论文集[C].陕西西安:2004:285-291.
[13]	张燎原.轴流压气机叶片排流场非定常频谱特性实验研究[D].江苏南京:南京航空航天大学,2004.
