两相多循环爆震波特性研究

张义宁; 王家骅; 张靖周

两相多循环爆震波特性研究

南京航空航天大学能源与动力学院, 南京 210016

基金项目: 国防基础预研项目(K1600060704)

计量
- 文章访问数: 1650
- HTML浏览量: 75
- PDF量: 406
- 被引次数: 0
出版历程
- 收稿日期: 2005-10-12
- 修回日期: 2005-11-30
- 刊出日期: 2006-10-28

Investigation of two-phase and multi-cycle detonation

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 为了研究两相爆震燃烧的特性,在多循环自吸式脉冲爆震原型机上进行试验研究。运用动态压力传感器和离子探针并行采集手段进行试验,结果表明:爆震波传播速度在1300m/s左右;爆震波的前导激波与反应区之间的距离在30mm左右,两相爆震的主要反应区厚度约为80mm左右,且反应区后存在液滴的燃烧延迟;激波动态压力信号与反应区的离子信号的并行采集可以作为判断是否产生爆震的手段。
- 航空、航天推进系统 /
- 脉冲爆震发动机(PDE) /
- 爆震波 /
- 两相 /
- 原型机
Abstract: In order to study the two-phase detonation wave characteristics,a series of experiments at different frequencies were conducted on a pulse detonation engine(PDE) prototype,the diameter and the length of which are 58 mm and 1370 mm respectively.The data of dynamic pressure and ion signal were collected simultaneously in the PDE combustion chamber.The PDE prototype can work at frequency up to 50 Hz with gasoline/air mixture.The two-phase and multi-cycle detonation wave characteristics were described firstly from combustion mechanism.The detonation wave propagated at about 1300m/s,and the width of induction zone is about 30mm.The reaction zone width is about 80mm,and behind the reaction zone there exists reaction delay of liquid fuel drops.Data simultaneous collection can be used to judge whether actual detonation in the PDE combustion chamber occurs.
- aerospace propulsion system /
- Pulse Detonation Engine (PDE) /
- detonation wave /
- two-phase /
- prototype

HTML

参考文献(13)

[1]	陈义良,张孝春,孙慈,季鹤鸣.《燃烧原理》[M].北京:航空工业出版社,1992,185-231.
[2]	Shepherd J E,Pintgen F,Austin J M,et al.The structure of the detonation front in gases[R].AIAA 2002-0773.
[3]	Pintgen F,Eckett C A,Austin J M,et al.Direct observation of reaction zone structure in propagating detonation[J].Combustion and Flame,2003,133(3):211-229.
[4]	Lee S Y,Conrad C,Watts J,et al.Deflagration to detonation transition study using simultaneous schlieren and OH PLIF images[R].AIAA.2000-3217.
[5]	韩启祥.爆震机理及旋转阀脉冲爆震发动机原理样机研究[D].南京:南京航空航天大学,2004,15-19.
[6]	Shepherd J E,Austin J,ChaoT,et al.Detonation initiation,propagation,and structural response[R].Presentation for 14th ONR propulsion conference.2001.
[7]	Lasheras J,Varatharajan B,Varga C,et al.Studies of fuel distribution and detonation chemist for pulse detonation engines[R].ISABE-2001-1174,Bangalore,India,September 2001.
[8]	严传俊,范玮,黄希桥,等.脉冲爆震发动机性能分析[J].工程热物理学报,2004,25(增):217-220.Yan Chuan-jun,Fan Wei,H uang Xi-qiao,et al.Performance analysis of pulse detonation engines[J].Journal of Engineering Thermophysics,2004,25 (Suppl):217-220.
[9]	Cavrilenko T P,Prokhorov E S.Overdriven gaseous detonations[R].8th ICOGER,Minsk,USSR,1981,23-26.
[10]	Desbordes D.Transmission of overdriven plane detonations:Critical Diameter as a Function of Cell Regularity and Size[J].AIAA Journal,1988,68:170-185.
[11]	Brophy Christopher M,Netzer Dave,Forster Dave LT.Detonation studies of JP-10 with oxygen and air for pulse detonation engine development[R].AIAA 98-4003.
[12]	Dabora E K,Ragland K W,Nicholls J A.Drop size effects in spray detonations[R].Proceedings of the combustion onstitute,Lex-KM Publishers,Moscow,2001,12:19-26.
[13]	Dabora E K.AModel for spray detonations[J].Acta Astronautica,1979,6:269-280.
