双排簸箕形孔气膜冷却效率及其叠加算法

Film cooling and superposition method for double row dust-pan shaped holes

School of Power and Energy, Northwestern Polytechnical University, Xi′an 710072, China

摘要: 对双排错排簸箕形孔气膜冷却效率进行了实验研究,测出了孔排下游的局部冷却效率的分布。对比研究了单排孔与双排孔气膜冷却效率分布的特点及双排孔气膜冷却效率的叠加算法。结果表明,在单排孔条件下所确定的最佳吹风比,在多排孔喷射时是不适用的。在较高吹风比下,如采用传统的气膜冷却效率的叠加算法,根据单排孔冷却效率计算双排孔冷却效率会产生很大的偏差,其计算结果远低于试验值。给出了双排错排的簸箕形孔的喷射时,冷却效率的叠加计算关系式。
- 航空、航天推进系统 /
- 簸箕形孔 /
- 气膜冷却 /
- 叠加算法
Abstract: Film cooling effectiveness for injection from single row and double row dust-pan shaped holes has been studied experimentally.The differences of cooling performance between single row and double row holes were described.Results show that the optimal blowing ratio of injection from double row holes is higher than that of injection from single row holes.In the case of higher blowing ratio,the traditional superposition calculation method under-predicts the film cooling effectiveness of double row injection based on that of single row hole injection.The modified superposition calculation method is given in the present paper.
- aerospace propulsion system /
- dust-pan shaped hole /
- film cooling /
- superposition method

[1]	Sellers J P Jr.Gaseous Film Cooling with Multiple Injection Stations,[J].AIAA Journal,1965,1:2 154-2 156.
[2]	Sasaki M,Takahara K,Kumagai T,et al.Film cooling effectiveness for injection from multirow holes[J].Journal Engineering for Power,Tans.ASME,1979,101:101-107.
[3]	Takeishi K Aoki S,Sato T,Tsukagoshi K.Film cooling on a gas turbine rotor blade[J].Journal of Turbomachinery,1992,114:828-834.
[4]	朱惠人,许都纯,刘松龄.气膜孔形状对排孔下游冷却效率的影响.[J].航空学报,2002,23(1):75-78.Zhu Huiren,Xu Duchun,Liu Songling.Effects of hole shape on film cooling effectiveness[J].Acta Aeronautica ET Astronautica Sinica,2002,23(1):75-78.
