具有接触接合面的篦齿封严组件振动特性分析

Vibration performance of contact system of labyrinth assembly

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要: 运用弹性力学理论研究了篦齿封严组件及其减振结构之间过盈装配压力和接触刚度的求解方法,在此基础上给出了具有接触接合面的封严环/阻尼片组合结构动力特性的分析方法,并且研究了阻尼片厚度、阻尼片周向分布数量、装配过盈量等参数对结构动力特性的影响规律。转动情况下封严环离心应力与阻尼片厚度近似成线性关系;阻尼片的周向分布数量影响封严环的固有频率和振型;阻尼片沿周向分布数量越多,应力分布越均匀,封严环的离心应力越小。
- 航空、航天推进系统 /
- 过盈装配压力 /
- 接触刚度 /
- 封严组件 /
- 振动特性
Abstract: The analysis of contact system vibration is complex due to its non-linearity and chaotic behaviors in the process.This paper formulates the equivalent linear model of labyrinth assembly by introducing local contact rigidity and using vibration mechanical theory.The vibration performance of contact system of some types of labyrinth assembly is simulated with variable damper size,circumferential numbers and size of interference fit by using FEM software.The simulation results confirmed the validity of the proposed simplified model and relevant theory analysis.
- aerospace propulsion system /
- interference fit /
- local contact rigidity /
- labyrinth assembly /
- vibration performance

[1]	航空发动机设计手册第18册[M].北京:航空工业出版社,2001.
[2]	Johnson K L.接触力学[M].北京:高等教育出版社,1992.
[3]	张松,艾兴.高速主轴过盈连接特性研究[J].制造技术与机床,2003,10:87-90ZHANG Song,AI Xing.Study on the performance of interface fit for the high speed spindle[J].Manufacturing Technique and Machine Tool,2003,10:87-90.
[4]	张松,艾兴.基于有限元的高速旋转主轴过盈配合研究,机械科学与技术[J].机械科学与技术,2004,1,23:15-17.ZHANG Song,AI Xing.FEM-based study on interface fits in high speed rotary spindles[J].Mechanical Science and Technology,2004,1,23:15-17.
[5]	武瑛.非等长度组合厚壁圆筒装配压力[J].太原理工大学学报,2000,31:215-217.WuYing.The assembly pressure of circular tubes with different lengths[J].Journal of Tai Yuan University of Technology,2000,31:215-217.
[6]	刘鸿文.材料力学[M].北京:高等教育出版社,1979.
[7]	张锦,刘晓平.叶轮机振动模态分析理论及数值方法[M].北京:国防工业出版社,2001.
