一种确定低周应变疲劳应变-寿命曲线的方法

张国栋; 苏彬; 王泓; 钟斌; 许超

一种确定低周应变疲劳应变-寿命曲线的方法

张国栋¹,
苏彬¹,
王泓²,
钟斌¹,
许超¹

1.
北京航空材料研究院,北京 100095
2.
西北工业大学材料科学与工程学院, 西安 710072

计量
- 文章访问数: 2718
- HTML浏览量: 252
- PDF量: 442
- 被引次数: 0
出版历程
- 收稿日期: 2005-08-08
- 修回日期: 2005-12-09
- 刊出日期: 2006-10-28

A method for reducing strain-life curve of low cycle fatigue

1.
Beijing Institute of Aeronautical Materials, Beijing 100095, China
2.
School Material Science and Engineering, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 基于Manson-Coffin方程处理低周应变疲劳应变-寿命曲线,提出了一种在短寿命区用低周应变疲劳试验数据,长寿命区（5000周⁵0000周）用高周疲劳试验数据联合确定材料的高温低周应变疲劳应变-寿命曲线的方法。联合处理方法的应用将不再需要进行应变控制的长寿命小应变的疲劳试验,节约了试验经费,缩短了试验周期。用GH141合金760℃的低周应变疲劳和高周疲劳数据对该方法进行了验证,验证结果发现:联合处理方法和单纯的Manson-Coffin方程处理得到的应变-寿命曲线吻合很好。联合处理方法可以用来确定高温低周应变疲劳应变-寿命曲线。
- 航空、航天推进系统 /
- 低周疲劳 /
- 寿命 /
- 高周疲劳
Abstract: Based on Manson-Coffin equations of low cycle fatigue(LCF) under strain controlled to acquire strain-life curve,a new technique for determining strain-life curve of LCF is developed.When fatigue life is shorter than 5000 cycles,experimental data of LCF under strain controlled are used.But when fatigue life is longer than 5000 cycles,experimental data of high cycle fatigue(HCF) under stress controlled are employed.This new method of combining LCF with HCF allows to avoid long fatigue life with small strain test under strain controlled,thus test expenses may be saved and test time shortened.Experimental data of LCF and HCF are reduced by new method for superalloy GH141,at temperature 760℃. Strain-life curves obtained by simply Manson-Coffin equation and by new method are in good agreement.The new method combining by LCF with HCF can be used to get strain-life curve of LCF.
- aerospace propulsion system /
- low cycle fatigue(LCF) /
- life /
- high cycle fatigue(HCF)

HTML

参考文献(12)

[1]	GJB/Z 18-91,金属材料力学性能数据表达准则[S].北京:国防科工委军标出版发行部,1992.
[2]	Manson S S.A Complex Subject-Some Simple Approximations[J].Journal of Experiment Mechanics,1965,(57):193-226.
[3]	张国栋,苏彬,王泓,等.K403合金高温低周应变疲劳寿命预测方法研究[J].机械强度,2004,26(S):263-266.ZHang G D,Su B,Wang H,et al.Method of life prediction for low cycle fatigue in super-alloy K403[J].Journal of Mechanical Strength,2004,26(S):263-266.
[4]	谢济洲.低循环疲劳手册[M].北京:北京航空材料研究所,1991.28-32.
[5]	Coffin L F.The effect of frequency on high temperature low-cycle fatigue[A].In Proceedings of Air Force Con-ference on Fracture and Fatigue of Aircraft Structures[C].AFDL-TR-70-144,1970:301-312.
[6]	Ostergren W J.A damage function and associated failure equation for predicting hold time and frequency effects in elevated temperature low cycle fatigue[J].Journal of Testing and Evaluation,1976,4(5):327-339.
[7]	Manson S S,Halford G R,Hirschberg M H.Cree-p-fatigue analysis by strain-range partitioning[A].In D-esign for Elevated Temperature Environment[C],S.Y.Zam-rik,ed:ASME,1971:12-28.
[8]	Coffin L F.The concept of frequency separation in life prediction for time-dependent fatigue[A].ASME-MPCSymposium on Creep-Fatigue Interaction[C].MPC-3,1976:349-363.
[9]	He J,Duan Z,Ning Y,Zhao D.Strain energy partitioning and its application to GH33A nickel-base s-uperalloy and 1Cr18Ni9Ti stainless steel[A].In Advance in Life Prediction Methods[C].NY:D.A.Woodford and J.R.Whitehead eds.,ASME,1983:27-32.
[10]	MIL-HDBK-5J.航空与航天飞行器结构用金属材料与元件[S].美国空军,2003.
[11]	付惠民.三参数幂函数回归分析[J].航空动力学报,1994,9(2):186-190.Fu Huimin.Regression analysis of three-para-meter power function[J].Journal of Aerospace Power,1994,9(2):186-190.
[12]	韩希鹏,许超,段作祥,等.高周疲劳曲线的等效应力法[J].航空材料学报,2003,23(3):53-57.HAN Xi-peng,XU Chao,DUAN Zuo-xiaug,et al.Modified equivalent stress model for high cycle fati-gue curves[J].Journal of Aeronautical Materials,2003,23(3):53-57.
