低速压气机静叶非定常Clocking效应数值模拟

綦蕾; 邹正平; 陈浮; 徐国强; 丁水汀

低速压气机静叶非定常Clocking效应数值模拟

綦蕾^1,2,
邹正平^1,2,
陈浮³,
徐国强¹,
丁水汀¹

1.
北京航空航天大学能源与动力工程学院航空发动机气动热力重点实验室, 北京 100083
2.
北京航空航天大学航空发动机数值仿真研究中心, 北京 100083
3.
哈尔滨工业大学能源科学与工程学院, 黑龙江哈尔滨 150001

基金项目: 国家自然科学基金重点项目资助(50106002);国家自然科学基金资助(5010600150546013)

计量
- 文章访问数: 1636
- HTML浏览量: 173
- PDF量: 527
- 被引次数: 0
出版历程
- 收稿日期: 2005-08-04
- 修回日期: 2006-01-13
- 刊出日期: 2006-10-28

Numerical simulation of stator clocking effect in a low speed compressor

1.
National Key Laboratory on Aero-Engines, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China
2.
Aeroengine Numerical Simulation Research Center, Beijing University of Aeronautics and Astronautics, Beijing 100083, China
3.
School of Energy Science and Engineering, Harbin Institute of Technology, Harbin 150001, China

摘要

摘要: 采用三维粘性非定常数值模拟方法研究了重复级低速压气机内部非定常流动,其中包括静叶Clocking(时序)效应以及尾迹-边界层、尾迹-尾迹和尾迹-泄漏流的相互作用。对静叶时序效应的结果分析显示,当两级静叶相对周向位置改变时最大效率变化只有0.1%,表明低速压气机中静叶时序效应不明显。另外,非定常结果流动图画显示,在非定常环境下上游周期性尾迹的通过对下游叶片边界层、尾迹以及叶尖泄漏流的发展都有一定影响。
- 航空、航天推进系统 /
- Clocking效应 /
- 相互作用 /
- 非定常流动 /
- 低速压气机
Abstract: The unsteady flow in a low speed compressor with repeated stages was simulated by numerical simulation of 3-D viscous flow.The influence of clocking and the interaction of wake,boundary layer and leakage vortex were discussed.The results show that only a 0.1% overall efficiency variation due to clocking of the second stage stator is found,and it is considered that the clocking effects in low speed compressor is not distinct.The unsteady flow indicates that the upstream wake can influence the boundary layer,wake and leakage flow of the downstream flow.
- aerospace propulsion system /
- clocking effect /
- interaction /
- unsteady flow /
- low speed compressor

HTML

参考文献(14)

[1]	Huber F W,Johnson P D,Sharma O P,et al.Performance improvement through indexing of turbine airfoils:Part IExperimental investigation[J].ASME Journal of Turbomachinery,1996,118:630-635.
[2]	Andrea A,Michele M,Alberto S D G,et al.Numerical investigation of three-dimensional clocking effects in a low pressure turbine[J].ASME Journal of Turbomachinery,ASME Paper 2003-GT-38414.
[3]	Gundy-Burlet K L,Dorney D J.Investigation of airfoil clocking and inter-blade-row gaps in axial compressors[R].AIAA Paper 97-3008,33rd AIAA,ASME,SAE,and ASEE Joint Propulsion Conference,Seattle,WA,July 6-9,1997.
[4]	Gundy-Burlet K L,Dorney D J.Physics of airfoil clocking in axial compressors[R].ASME Paper 97-GT-444,ASME Turbo Expo 1997,Orlando,FL,2-5 June,1997.
[5]	Barankiewicz W S,Hathaway M D.Effects of stator indexing on performance in a low speed multistage axial compressor[R].ASME Paper 97-GT-496.
[6]	Keith Walters D,James H L.A CFD study of wake-induced transition on a compressor-like flat plate[R].ASME Paper 2003-GT-38680.
[7]	Maik T,Friedrich K.Some aspects of wake-wake interactions regarding turbine stator clocking[R].ASME Paper 2000-GT-487.
[8]	Hodson H P.Boundary layer and loss measurements on the rotor of an axial flow turbine[J].Journal of Engineering for Gas Turbines and Power,1984,106:391-399.
[9]	邹正平,徐力平.双重时间步方法在非定常流场模拟中的应用[J].航空学报,2000,21(4):317-321.Zou Zhengping,Xu Liping.Prediction of 3-D unsteady flow using implicit dual time step approach[J].Acta Aeronautica et Astronatica Sinica,2000,21 (4):317-321.
[10]	侯安平,周盛.轴流式叶轮机时序效应的机理探讨[J].航空动力学报,2003,18(1):70-75.Hou Anping,Zhou Sheng.Probe into the mechanism of clocking effect in turbomachinery[J].Journal of Aerospace Power,2003,18(1):70-75.
[11]	Korakianitis T.On the propagation of viscous wakes and potential flow in axial-turbine cascade[J].ASME Journal of Turbomachinery,1993,115(1):118-127.
[12]	Hodson H P.Blade row interactions in low pressure turbines[R].Lecture series 1998-02,Von Kármán Institute,Blade Row Interference Effects in Axial Turbomachinery Stages.
[13]	Yi-Chih C,Oguz U,Joseph K.On the flow and turbulence within the wake and boundary layer of a rotor blade located downstream of an IGV[R].ASME Paper 2003-GT38599.
[14]	Chow Y C,Uzol O,Kata J.Flow non-uniformities and turbulent "hot spots" due to wake-blade and wake-wake interactions in a multistage turbomachine[R].ASME Paper 2002-GT-30667.
