预应力作用下弧齿锥齿轮的动频率计算

李盛鹏; 方宗德

预应力作用下弧齿锥齿轮的动频率计算

西北工业大学机电工程学院, 陕西西安 710072

基金项目: 国家自然科学基金资助(50475148);航空科学基金资助(04C53015)

计量
- 文章访问数: 1951
- HTML浏览量: 104
- PDF量: 403
- 被引次数: 0
出版历程
- 收稿日期: 2005-08-10
- 修回日期: 2005-12-06
- 刊出日期: 2006-10-28

Dynamic frequency calculation of the spiral bevel gear under prestress

School of Mechatronic Engineering, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 弧齿锥齿轮是航空发动机中的基本元件,常发生共振破坏。运用自主开发的弧齿锥齿轮设计分析系统建立了包含齿轮完整结构的有限元网格模型,并导入ANSYS软件中进行了考虑工作转速和啮合扭矩引起的预应力影响的弧齿锥齿轮动频率计算,结果表明工作转速引起的离心力和啮合扭矩对弧齿锥齿轮的振动频率有一定的影响。
- 航空、航天推进系统 /
- 弧齿锥齿轮 /
- 动频率 /
- 转速 /
- 啮合扭矩 /
- ANSYS
Abstract: Being an important part in aero-engine,the spiral bevel gears were frequently destroyed from syntony.A modal analysis of the spiral bevel gears under prestress caused by rotating speed and meshing torque was carried out by ANSYS.Dynamic frequencies of the spiral bevel gears with different geometrical parameters were calculated.The finite element models were established using a design and analysis system of spiral bevel gear which had been developed by ourselves.The result shows that rotating speed and meshing torque have certain effect on dynamic frequency.
- aerospace propulsion system /
- spiral bevel gear /
- dynamic frequency /
- rotating speed /
- meshing torque /
- ANSYS

HTML

参考文献(8)

[1]	郭星辉,鄂中凯,陈良玉,等.弧齿锥齿轮波动共振条件分析[J].航空动力学报,1995,10(1):13-16.Guo Xinghui,E Zhongkai,Chen Liangyu.Fluctuating resonance analysis of spiral bevel gear[J].Journal of Aerospace Power,1995,10(1):13-16.
[2]	邹豪,鄂中凯,陈良玉,等.高速弧齿锥齿轮动频计算[J].东北大学学报(自然科学版),1996,17(5):549-553.Zou Hao,E Zhongkai,CHEN Liangyu,et al.High-speed spiral bevel gears' dynamic frequency calculation[J].Journal of Northeastern University (Natural Science),1996,17(5):549-553.
[3]	刘更,沈允文,蔺天存,等.具有不同腹板布置的薄轮缘圆柱齿轮的模态实验[J].机械科学与技术,1995,4:89-92.Liu Geng,Shen Yunwen,Lin Tiancun,et al.Modal experiment on thin-rimmed cylindrical gears with different web arrangments[J].Mechanical Science and Technology,1995,4:89-92.
[4]	杨宏斌,高建平,邓效忠,等.弧齿锥齿轮和准双曲面齿轮非线性动力学研究[J].航空动力学报,2004,19(1):54-57.Yang Hongbin,Gao Jianping,Deng Xiaozhong,et al.Nonlinear dynamics of spiral bevel gears and hypoid gear drives[J].Journal of Aerospace Power,2004,19 (1):54-57.
[5]	綦耀光,陈如恒,韩维法.双圆弧齿轮轮齿的固有频率与振型分析[J].机械传动,1996,20(2):19-22.Qi Yaoguang,Chen Ruheng,Han Weifa.Natural frequency and vibration mode of double circular-arc helical gear[J].Journal of Mechanical Transmission,1996,20(2):19-22.
[6]	刘辉,吴昌林,杨叔子.基于有限元法的斜齿轮体模态计算与分析[J].华中理工大学学报,1998,26(11):75-77.Liu Hui,Ww Changlin,Yang Shuzi.Calculation and analysis of a mode for helical gear based on FEM[J].Journal of Huazhong University of Science and Technology,1998,26(11):75-77.
[7]	唐增宝,钟毅芳.齿轮传动的振动分析与动态优化设计[M].湖北武汉:华中理工大学出版社,1994.
[8]	叶先磊,史亚杰.ANSYS工程分析软件应用实例[M].北京:清华大学出版社,2003.
