电控旋翼气弹动力学建模研究

陆洋; 王浩文; 高正

电控旋翼气弹动力学建模研究

南京航空航天大学直升机旋翼动力学国家级重点实验室, 江苏南京 10016

基金项目: 国防重点实验室基金资助(51463020101ZS52)

计量
- 文章访问数: 1734
- HTML浏览量: 208
- PDF量: 443
- 被引次数: 0
出版历程
- 收稿日期: 2006-02-09
- 修回日期: 2006-09-26
- 刊出日期: 2006-12-28

Aeroelastic dynamic modeling of the Electrically Controlled Rotor

National Key Laboratory of Rotorcraft Aeromechnaics, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 研究了电控旋翼的气弹动力学建模方法。以有限元旋翼气弹分析程序LORA01为基础,首先给出了一种能计及襟翼移轴补偿影响的时域综合非定常气动力模型,并将伺服襟翼作为额外引入的质量体计入结构动力学模型;之后结合有限元法,根据Hamilton原理导出由广义力表示的带襟翼桨叶非线性运动方程,采用基于Newmark方法的隐式数值积分法对桨叶运动方程进行求解。最后,利用主动控制襟翼旋翼的试验数据对模型进行了比较验证,证明了所建模型的正确性。
- 航空、航天推进系统 /
- 电控旋翼 /
- 襟翼 /
- 气弹动力学 /
- 建模 /
- 空气动力学 /
- 结构动力学
Abstract: For the purpose of aeroelastic analysis of the Electrically Controlled Rotor(ECR),an aeroelastic dynamic model is built in this paper.Firstly,a synthetic unsteady aerodynamic model in time domain is presented,which can take account of the unsteady effect of the flap nose overhang.The inertia effect of the flap is introduced into the structural dynamic model as an independent mass.According to the Hamilton principle,the nonlinear motion equation of the blade with flap is deduced with the form of generalized forces.Then,based on the finite element aeroelastic analysis code LORA01,the implicit equation of ECR blade motion is solved by an improved Newmark numerical integration method.At last,the ECR aeroelastic dynamic model is validated through comparison with the test results of the Active Control Flap(ACF) rotor.
- aerospace propulsion system /
- electrically controlled rotor /
- flap /
- aeroelastic dynamics /
- modeling /
- aerodynamics /
- structural dynamics

HTML

参考文献(13)

[1]	Aiken E,Ormiston R,Young L A.Future directions in rotorcraft technology at ames research center[A].American Helicopter Society 56th Annual Forum[C].2000:10-30.
[2]	陆洋,王浩文.电控伺服襟翼旋翼-一种新概念旋翼系统[A].第十八届全国直升机年会论文集[C].昆明:2002:7-12.Lu Yang,Wang Hao-wen.Electrically controlled rotor-a new concept rotor system[A].18th China Helicopter Forum[C].Kunmin:2002:7-12.
[3]	Shen J W,Chopra I.Actuation requirements for a swashplateless helicoter control system with trailing-edge flaps[R].AIAA-2002-1444.
[4]	Shen J W,Chopra I,Johnson W.Performance of swashplateless ultralight helicopter rotor with trailing-edge for primary flight control[A].American Helicopter Society 59th Annual Forum[C].2003:256-266.
[5]	Shen J W,Chopra I.A parametric design study for a swashplateless helicopter rotor with trailing-edge flaps[J].Journal of the American Helicopter Society,2004,49(1):43-53.
[6]	Milgram J,Chopra I,Straub F A.Comprehensive rotorcraft aeroelastic analysis with trailing edge model:validation with experimental data[A].American Helicopter Society 52nd Annual Forum[C].1996:715-735.
[7]	Milgram J.A comprehensive aeroelastic analysis of helicopter main rotors with trailing edge flaps for vibration reduction[D].University of Maryland,1997.
[8]	Straub F K,Charles B D.Aeroelastic analysis of rotors with trailing edge flaps using comprehensive codes[J].Journal of the American Helicopter Society,July,2001:192-199.
[9]	Wang H W,Gao Z.Rotor vibratory loads prediction based on generalized forces[J].Chinese Journal of Aeronautics,2004,17(1):17-21.
[10]	陆洋,王浩文,高正.用于电控旋翼气弹分析的带襟翼翼型气动力模型[J].空气动力学学报,2005,23(2):243-247.Lu Yang,Wang Hao-wen,Gao Zheng.Aerodynamic model of airfoil with flap used for electrically controlled rotor aeroelastic analysis[J].Journal of Aerodynamics,2005,23(2):243-247.
[11]	Leishman J G,Beddoes T S.A generalized model for airfoil unsteady aerodynamic behavior and dynamic stall using the indicial method[A].American Helicopter Society 42nd Annual Forum[C].June,1986:243-265.
[12]	Hariharan N,Leishman J G.Unsteady aerodynamics of a flapped airfoil in subsonic flow by indicial concepts[A].36th AIAA/ASME/ASCE/AHS/ASC Structures,Structural Dynamics,and Materials Conference[C].April,1995:613-634.
[13]	Theodorsen T,Garrick I E.Nonstationary flow about a wing-aileron-tab combination including aerodynamic balance[R].NACA-736,1942.
