腔内平板对空腔自激励振荡的影响及预估振荡频率方程的改进

司海青; 王同光; 宗慧英

腔内平板对空腔自激励振荡的影响及预估振荡频率方程的改进

南京航空航天大学航空宇航学院, 江苏南京 210016

计量
- 文章访问数: 2177
- HTML浏览量: 77
- PDF量: 485
- 被引次数: 0
出版历程
- 收稿日期: 2005-12-12
- 修回日期: 2006-03-26
- 刊出日期: 2006-12-28

Influence of the plate on the cavity flow-induced oscillations and the modification of the oscillation frequency equation

College of Aerospace Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 运用全隐式无分裂方法,紊流模型采用修正的B-L代数模型,数值模拟了超音速流通过腔内存在平板的空腔流动。研究了腔内有不同长度平板存在的空腔流动的剪切层自持性振荡,并与无平板存在时的现象进行类比。腔内平板将剪切层与空腔隔开,减弱了剪切层振荡与空腔压强脉动的耦合作用;随着腔内平板长度的增加,剪切层振荡的程度有所减小。基于特征长度可变的思想,本文改进了Heller的频率预估方程,改进后的频率方程能更好地预估空腔的振荡频率。与Heller的方程相比,修改后的方程预估所得到的频率值更接近于闭式空腔声学模型方程的预估结果;各个方程预估空腔振荡频率值的比较进一步验证了改进后的方程的正确性及合理性。
- 航空、航天推进系统 /
- 全隐式无分裂方法 /
- N-S方程 /
- 空腔流动振荡 /
- 预估振荡频率方程
Abstract: A numerical solution of the three-dimensional URANS equation was presented using the fully implicit unfactored methods,where the turbulent coefficient was calculated based on the revised B-L turbulence model,and numerical simulations were implemented for supersonic three-dimensional open cavities.The self-sustained oscillatory motion of the shear layer was studied for plates with different lengths.The plate in the cavity isolates the shear layer and the cavity,and therefore reduces the coupling between the cavity pressure fluctuations and the shear layer.The oscillation of the shear layer decreases with the increase of the plate length.Based on the different characteristic lengths,Heller’s frequency equation was modified.The frequencies predicted by the modified equation agree with those by the close-box acoustic model;several comparisons demonstrate the validity of the modified equation.
- aerospace propulsion system /
- fully implicit unfactored method /
- N-S equations /
- cavity flow-induced oscillation /
- predicted oscillation frequency equation

HTML

参考文献(8)

[1]	Rossiter J E.Wind tunnel experiments on the flow over rectangular cavities at subsonic and transonic speeds[R].Ministry of Aviation,Aeronautical Research Council,R&M3438,1964.
[2]	Heller H H,Bliss D B.The physics mechanisms of flow induced press fluctuation in cavies and concepts for their suppression[R].AIAA Paper-1975-491.
[3]	Unalmis O H,Clemens N T,Dolling D S.Cavity oscillation mechanisms in high-speed flows[J].AIAA Journal,2004,42(10):2 035-2 041.
[4]	Mark F Reeder,Subramanian C.Mean and instantaneous flow properties of an object exiting a cavity[R].AIAA-2003-3723.
[5]	Arunajatesan S,Sinha N,Menon S.Towards hybrid LES-RANS computations of cavity flowfields[R].AIAA paper-2000-0401.
[6]	Baysal O,Srinivasan S,Stalling R L.Unsteady viscous calculations of supersonic flows past deep and shallow three dimensional cavities[R].AIAA-88-0101.
[7]	Si H,Wang T,Luo X.A fully lmplicit solver of 3-D euler equations on multiblock curvilinear grids[J].Modern Physics Letters B,2005,19(28-29):1483-1486.
[8]	Bauer R C,Dix R E.Engineering model of unsteady flow in a cavity[R].Calspan Corp./ AEDC Operations,Arnold Engineering Development Center TR-91-17,Dec.1991.
