轴流风机中支板通道的流动分析及改进

张夏; 楚武利; 邓文剑; 张皓光; 杨泳

轴流风机中支板通道的流动分析及改进

西北工业大学动力与能源学院, 陕西西安 710072

基金项目: 西北工业大学研究生创业种子基金资助(Z200536);航空基础科学基金资助(05C53016)

计量
- 文章访问数: 1632
- HTML浏览量: 151
- PDF量: 450
- 被引次数: 0
出版历程
- 收稿日期: 2005-12-12
- 修回日期: 2006-03-20
- 刊出日期: 2006-12-28

Flow analysis and the improvement of axial fan support strut

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 采用了NUMECA FINE软件包Euranus求解器对轴流风机电机支板内部流动进行了全三维数值模拟,结果表明电机支板的安装对风机的性能具有较大的影响。根据计算结果对支板结构进行了改型设计,并对改型后轴流风机的气动性能进行了数值计算,改型结果表明,采用改型后的支板结构使得整个流量范围内风机的效率有所提高,电机支板内部流动损失明显减小,流动更加合理。
- 航空、航天推进系统 /
- 轴流风机 /
- 支板 /
- 效率 /
- 损失 /
- 数值模拟
Abstract: Three-dimensional numerical investigation were carried out to investigate the flow-field in the passage between support struts in front of the axial-flow fan with the help of the commercial code EURANUS,which is an integral part of the software package NUMECA FINE.It was found that the support strut had significant impact on the axial-flow fan performance.The optimization design was performed for the support strut based on numerical result and flow analysis.In addition,three-dimensional flow analysis was carried out to verify the performance improvement of the newly optimized support strut.It was found that with the new strut the efficiency of the fan is improved over the entire range of mass flow,the losses are locally reduced and the flow in the passage between the support struts becomes more reasonable.
- aerospace propulsion system /
- axial fan /
- support strut /
- efficiency /
- loss,numerical simulation /

HTML

参考文献(7)

[1]	王正明,贾希诚.环形叶栅中二次流与损失的数值模拟[J].工程热物理学报,1999,20(4):444-447.Wang Zheng-ming,Jia Xi-cheng.Numerical simulation of secondary flow and losses in an annular casade[J].Journal of Engineering Thernophysics,1999,20(4):444-447.
[2]	钟兢军,苏杰先,王仲奇.压气机叶栅壁面拓扑和二次流结构分析[J].工程热物理学报,1998,19(1):40-44.Zhong Jing-jun,Su Jie-xian,Wang Zhong-qi.Analysis of topological and secondary flow structure in compressor cascade[J].Journal of Engineering Thernophysics,1998,19(1):40-44.
[3]	Ohkita Y,Kodama H,Nozaki O,et al.Numerical and experiment investigation of secondary flow in a high-speed compressor stator (952GT2229)[J].ASME Journal of Turbomachinery,1997,119(2):169-175.
[4]	周笃高,孙秀景.低压轴流风机后导叶栅结构参数的最佳选择[J].矿山机械,1996,(6):48-50.Zhou Du-gao,Sun Xiu-jing.Optimum design for structural parameters of swept back blades of low-pressure axial fan[J].Mining & Processing Equipment,1996,(6):48-50.
[5]	王岳.矿用局部轴流通风机气动优化设计[J].抚顺石油学院学报,1996,16(2):30-35.Wang Yue.Optimal aerodynamic design for mine local fans[J].Journal of Fushun Petroleum institute,1996,16(2):30-35
[6]	Spalart P R,Almaras S R.A one-equation turbulence model for aerodynamic flows[R].AIAA Paper,92-0439.
[7]	NUMECA.User manual[Z].IGGTM Version4.7-1,February 2003.
