组合畸变对某型发动机稳定性的影响

黄顺洲; 胡骏

组合畸变对某型发动机稳定性的影响

黄顺洲,
胡骏

南京航空航天大学能源与动力学院, 南京 210016

计量
- 文章访问数: 1731
- HTML浏览量: 193
- PDF量: 478
- 被引次数: 0
出版历程
- 收稿日期: 2005-11-18
- 修回日期: 2006-03-27
- 刊出日期: 2006-12-28

Investigation of the effect of combined distortion on engine stability

College of Energy and Power Engineering, Nanjing University of Astronautics and Aeronautics, Nanjing 210016, P. R. China

摘要

摘要: 压力和温度组合畸变对某涡轮风扇发动机稳定性影响的数值研究表明,该发动机的进口临界压力畸变强度和临界温度畸变强度分别为8.82%和8.60%,风扇的压力畸变敏感系数为2.608,高压压气机的温度畸变敏感系数为2.442。压力畸变和温度畸变的相对大小,决定了组合畸变对风扇或压气机稳定性影响的严重程度。压力畸变的相对最大强度峰值出现在风扇截面时,风扇首先失稳,反之则高压压气机首先失稳。组合畸变对发动机稳定性的影响,不是压力畸变和温度畸变单独影响的简单相加,而是一种非常复杂的非线性关系。
- 航空、航天推进系统 /
- 压力畸变 /
- 温度畸变 /
- 组合畸变 /
- 发动机稳定性
Abstract: The calculated effect of combined distortion on the engine stability shows that the critical values of pressure and temperature distortion are 8.82% and 8.60% respectively.The pressure distortion coefficient of the fan is 2.608 and the temperature distortion coefficient of the compressor is 2.442.The magnitude of pressure distortion and temperature distortion determines the severity of the combined distortion effect on the fan or compressor stability.When the relative peak intensity of distortion appears at the fan section,the fan falls into instability first,otherwise the compressor does.The effect of the combined distortion on engine stability can’t be calculated by superposing the effect of the pressure distortion to the temperature distortion simply,but in a complex nonlinear manner.
- aerospace propulsion system /
- pressure distortion /
- temperature distortion /
- combined distortion /
- engine stability

HTML

参考文献(7)

[1]	GJB/Z64-2003.航空涡轮喷气和涡轮风扇发动机进口总压畸变评定指南[S].北京:中国航空综合技术研究所,2003年12月.
[2]	刘大响,叶培梁,胡骏,等.航空燃气涡轮发动机稳定性设计与评定技术[M].北京:航空工业出版社,2004年6月.
[3]	Graber E J,Braithwaite W M.Summary of recent investigations of inlet flow distortion effects on engine stability[R].AIAA Paper74-236,1974.
[4]	Abdelwahab M.Effects of temperature transients at fan inlet of a turbofan engine[R].NASA TP-1031,1977.
[5]	Brithwaite W M,Soeder r H,Combined pressure and temperature distortion effects on internal flow of a turbofan engine[R].AIAA Paper79-1309,1979.
[6]	Soeder R H,Bobula G A.Effects of steady-state temperature and combined distortion on Inlet flow to a turbofan engine[R].NASA TM-79237,1979.
[7]	Soeder R H,Mehalic C M.Effect of combined pressure and temperature distortion orientation on high-bypass-ratio turbofan engine stability[R].NASA TM-83771,1984.
