基于相关积分法的离心压气机喘振过程的非线性监测

孙涛; 徐光华; 张春梅

基于相关积分法的离心压气机喘振过程的非线性监测

1.
西安交通大学机械工程学院, 陕西西安 710049
2.
西安交通大学机械制造系统工程国家重点实验室, 陕西西安 710049
3.
西安交通大学能源与动力工程学院, 陕西西安 710049

基金项目: 国家重大产业化专项项目——大型透平压缩机组集散监控系统高技术产业化示范工程

计量
- 文章访问数: 1922
- HTML浏览量: 231
- PDF量: 478
- 被引次数: 0
出版历程
- 收稿日期: 2005-11-15
- 修回日期: 2006-04-23
- 刊出日期: 2006-12-28

Nonlinear monitoring of the centrifugal compressor surge process based on the correlation integral method

1.
School of Mechanical Engineering, Xi′an Jiaotong University, Xi′an 710049, China
2.
State Key Laboratory of manufacturing System Engineering, Xi′an Jiaotong University, Xi′an 710049, China
3.
School of Energy and Power Engineering, Xi′an Jiaotong University, Xi′an 710049, China

摘要

摘要: 相关积分算式中参考距离的取值显著影响计算结果,本文以相关积分值的物理意义和两点距离序列的分布规律为依据引出了参考距离的取值原则。为了定量分析离心压气机失稳和喘振的程度,分别定义了基于参考距离的相对非平稳度和基于相关积分值的喘振强度。以实验分析论证了相关积分值等三个监测参数在离心压气机运行工况监测、喘振强度辨识和压力信号非平稳性度量中的有效性。
- 航空、航天推进系统 /
- 离心压气机 /
- 相关积分法 /
- 喘振 /
- 工况监测
Abstract: The reference distance in the correlation integral formula affects the computational value of correlation integral dramatically.In this paper,the method of setting values for the reference distance was presented on the basis of the physical meaning of the correlation integral value and the distribution of all inter-points distances at different operating conditions.Relative degree of unsteadiness based on the reference distance and intensity of surge based on the correlation integral value were defined to analyze the degree of instability and surge in centrifugal compressors quantitatively.By means of applying these measuring parameters to a case of our experiment,it demonstrates that the correlation integral value,etc.are effective for the nonlinear monitoring of operating condition,identification of surge intensity and measuring of pressure unsteadiness in centrifugal compressors.
- aerospace propulsion system /
- centrifugal compressor /
- correlation integral method /
- surge /
- condition monitoring

HTML

参考文献(12)

[1]	张靖煊.一种捕捉预示压气机失稳预警信号的新方法的研究.航空动力学报,2004,19(2):270-277.Zhang Jing-xuan.Study of a new method for giving warning signals of instability[J].Journal of Aerospace Power,2004,19(2):270-277.
[2]	宋慧敏,李应红,吴云,等.基于自相关函数的压气机气动不稳定监测方法[J].空军工程大学学报(自然科学版),2005,16(3):7-9.Song Hui-min,Li Ying-hong,Wu Yun,et al.Sensing the aerodynamic instability of compressor using auto-correlation function[J].Journal of air force engineering university (Natural Science Edition),2005,16(3):7-9.
[3]	Leinhos D,Schmid N R,Fottner L.The influence of transient inlet distortions on the instability inception of a low-pressure compressor in a turbofan engine[J].ASME J.Turbomachinery,2001,123(1):1-8.
[4]	Hss B,Leinhos D,Fottner L.Stall inception in the compressor system of a turbofan engine[J].ASME J.Turbomachinery,2000,122(1):32-44.
[5]	陈超,程礼.基于关联维数的发动机转子振动故障模式判别[J].燃气涡轮试验与研究,2004,17(3):17-22.Chen Chao,Cheng Li.Vibration fault mode determination for engine rotor based on correlation dimension[J].Gas Turbine Experiment and Research,2004,17(3):17-22.
[6]	顾春伟,晋宏师,长岛利夫,等.叶轮机械内部不稳定流动现象的研究[A].中国工程热物理学会热机气动热力学学术会议论文集[C].北京:2005,505-510.
[7]	Bright M M,Qammar H K,Weigl H J,et al.Stall precursor identification in high-speed compressor stages using chaotic time series analysis methods[J].ASME Journal of Turbomachinery,1997,119:491-499.
[8]	Bright M M,Helen K Q,Wang L.Investigation of pre-stall mode and pip inception in high speed compression through the use of correlation integral[J].AEME Journal of Turbomachinary,1999,121:743-750.
[9]	吴云,张朴,李应红,等.基于相关积分方法的压气机气动不稳定监测[A].中国工程热物理学会热机气动热力学学术会议论文集[C].西安:2004:434-439.
[10]	李美林.基于小波分析的离心压气机喘振实验研究[D].西安:西安交通大学,2001.
[11]	Grassberger D A,Procaccia I.Measuring the strangeness of strange attractors[J].Phasica D,1983(9):189-208.
[12]	关惠玲,阎献国,张优云.动态过程非平稳性度量及其在设备诊断工程中的应用[J].机械工程学报,2003,39(8):141-145.Guan Hui-ling,Yan Xian-guo,Zhang You-yun.Unsteadiness measurement of dynamic process and its application to equipment diagnosing engineering[J].Chinese Journal of Mechanical Engineering,2003,39(8):141-145.
