基于优化拟形的航空发动机控制器降阶方法

李秋红; 孙健国; 许光华

基于优化拟形的航空发动机控制器降阶方法

南京航空航天大学能源与动力学院, 南京 210016

基金项目: 国家自然科学基金资助(50576033);航空科学基金资助(04C52019)

计量
- 文章访问数: 1833
- HTML浏览量: 186
- PDF量: 457
- 被引次数: 0
出版历程
- 收稿日期: 2005-11-22
- 修回日期: 2006-05-08
- 刊出日期: 2006-12-28

Model reduction method based on optimization shaping for aero-engine controller

College of Energy & Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 提出了一种基于优化输出拟形的航空发动机多变量控制器降阶方法,并以LQG/LTR控制器降阶为例,成功地将原控制器从8阶降为3阶。首先将控制器分为积分环节部分和稳定子系统部分,采用输出拟形的方法用低阶系统去逼近稳定子系统使二者具有相近的阶跃响应,利用遗传算法优化出低阶系统的参数,将低阶系统和分离出来的积分环节合并后即得到降阶后的控制器。与采用平衡截取Schur降阶方法比较,本方法可将系统阶次降得更低并取得更好的动态响应效果。
- 航空、航天推进系统 /
- 航空发动机 /
- 模型降阶 /
- 输出拟形 /
- 遗传算法 /
- 优化
Abstract: The model reduction method for aero-engine controller based on the optimization output shaping is presented in this paper.Using the LQG/LTR controller as an example,the 8~(th) order LQG/LTR controller is successfully reduced to a 3~(th) order system with this method.First the controller is divided into the integral part and the stable part.A lower order system is used to approach the stable part.With the optimization output shaping method,the lower order system parameters can be calculated using genetic algorithm(GA).Then the step response of them is very close to each other.At last,combining the optimized lower order system with the separated integral part,the reduced order controller can be obtained.Compared with the balanced truncation Schur model reduction method,this method can make the system with lower order and get better dynamic performance.
- aerospace propulsion system /
- aero-engine /
- model reduction /
- output shaping /
- genetic algorithm /
- optimization

HTML

参考文献(13)

[1]	Moore B C.Principal component analysis in linear systems:Controllability,observability and model reduction[J].IEEE Trans.Automat.Contr.,198l,AC-26(1):17-31.
[2]	Safonov M G,Chiang R Y.A schur method for balanced truncation model reduction[J].IEEE,Trans.Automat.Contr.,1989,AC-34(7):729-733.
[3]	Tatjana,Stykel.Gramian-based model reduction for descriptor systems[J].Mathematics of Control,Signals,and Systems,2004,16:297-319.
[4]	Fuchen Han,Taofang Hai.Nonconvex stochastic optimization for model reduction[J].Journal of Global Optimization,2002,23:359-372.
[5]	Diab M,Liu W Q,Sreeram V.Optimal model reduction with a frequency weighted extension[J].Dynamics and Control,2000,10:255-276.
[6]	Xie Li-hua,Zhang Ci-shen,Li Luo-wen.A gradient flow approach to optimal model reduction of discrete-time periodic systems[J].Journal of Global Optimization,2002,23:373-399.
[7]	杨刚.多变量鲁棒控制在航空发动机中的应用研究与实验验证[R].南京:南京航空航天大学,2004.
[8]	Yang Gang,Sun Jian-guo.Reduced order H∞/LTR method for aeroengine control system[J].Chinese Journal of Aeronautics,2004,17(3):129-135.
[9]	Nagar S K,Singh S K.An algorithmic approach for system decomposition and balanced realized model reduction[J].Journal of the Franklin Institute,2004,341:615-630.
[10]	Mukherjeea S,Satakshib,Mittal R C.Model order reduction using response-matching technique[J].Journal of the Franklin Institute,2005,342:503-519.
[11]	李秋红,孙健国,周继超.航空发动机PID控制参数优化的改进遗传算法[J].南京航空航天大学学报,2006,38(2):162-165.Li Qiu-hong,Sun Jian-guo,Zhou Ju-chao.Improved algorithm for calculating GA fitness function of aeroengine PID controller parameter optimazation[J].Journal of Nanjing University of Aeronautics & Astronautics,2006,38(2):162-165.
[12]	冯正平,孙健国,黄金泉,等.一种建立航空发动机状态变量模型的新方法[J],航空动力学报,1998,13(4):435-438.Feng Zheng-ping,Sun Jian-guo,Huang Jin-quan,et al.A new method for establishing a state variable model of aero-engine[J].Journal of Aerospace Power,1998,13(4):435-438.
[13]	张明君,张化光.基于遗传算法优化的神经网络PID控制器[J].吉林大学学报(工学版),2005,35(1):91-96.Zhang Ming-jun,Zhang Hua-guang.Neural network PID controller optimized by GA[J].Journal of Jilin University (Engineering and Technology Edition),2005,35(1):91-96.
