潜入喷管背壁区熔渣沉积的机理分析与数值模拟

魏超; 侯晓

潜入喷管背壁区熔渣沉积的机理分析与数值模拟

魏超,
侯晓

中国航天科技集团四院, 陕西西安 710025

计量
- 文章访问数: 1745
- HTML浏览量: 91
- PDF量: 454
- 被引次数: 0
出版历程
- 收稿日期: 2005-11-29
- 修回日期: 2006-05-18
- 刊出日期: 2006-12-28

Mechanism investigation and numerical simulation of slag deposition for submerged nozzle

WEI Chao,
HOU Xiao

The Fourth Academy of CASC, Xi'an 710025, China

摘要

摘要: 为了探求固体火箭发动机潜入喷管背壁区中熔渣沉积的机理和预估方法,采用欧拉-拉格朗日法模拟两相内流场,采用随机轨道模型跟踪离散相轨迹,确定了燃烧室中粒子的直径分布和两种熔渣捕获判据,分析了不同壁面恢复系数对熔渣沉积计算的影响,计算得到的熔渣最小占Al₂O₃总生成量的0.201%,最大占到0.287%。与实验数据对比证明该预估方法是准确可靠的。
- 航空、航天推进系统 /
- 固体推进剂火箭发动机 /
- 两相流场 /
- 潜入喷管 /
- 熔渣沉积
Abstract: In order to explore the mechanism and the model of slag generation in solid propellant rocket motor,the two phase flowfield has been simulated using a combined Eulerian-Lagrangian analysis.The motion of the particulate phase was tracked with a stochastic model.The droplet size distribution in the chamber and the two captive rules were considered.Finally,the influence of different coefficients of restitution on slag calculation was investigated.The calculated result shows that the lowest slag weight is 0.201% and the highest slag weight is 0.287% of the total weight of Al₂O₃.The results are accurate and credible compared to the experimental data.
- aerospace propulsion system /
- solid propellant rocket motor /
- two-phase internal flow /
- submerged nozzle /
- slag deposition

HTML

参考文献(16)

[1]	Salita M.Deficiencies and requirement in modeling of slag generation in solid rocket motor[J].Journal of Propulsion and Power,1995,11(1):10-23.
[2]	Salita M.Predicted slag deposition histories in eight solid rocket motors using the CFD "EVT"[R].AIAA 95-2728,1995.
[3]	何洪庆,周旭.固体火箭发动机燃烧室中的颗粒轨迹[J].推进技术,1999,20(5):25-29.He Hong-qing,Zhou Xu.Particle trajectories in combustion chamber of solid rocket motor[J].Journal of Propulsion Technology,1999,20(5):25-29.
[4]	李江,蔡体敏,肖育民,等.用RTR技术确定SRM燃烧室凝相粒子加入边界条件[J].推进技术,1999,20(5):30-34.Li Jiang,Cai Ti-min,Xiao Yu-min,et al.Determination of injection boundary condition of particles in SRM chamber based on RTR techniques[J].Journal of Propulsion Technology,1999,20(5):30-34.
[5]	李江,肖育民,何国强,等.固体火箭发动机燃烧室两相流粒子运动轨迹的实验研究[J].西北工业大学学报,1999,17(1):15-18.Li Jiang,Xiao Yu-min,He Guo-qiang,et al.Experimental study of partlcle trajectorles in soild rocket motor chamber[J].Journal of Northwestern Polytechnical University,1999,17(1):15-18.
[6]	胡春波,何国强,刘佩进,等.潜入喷管背壁区熔渣溢流沉积实验研究[J].推进技术,2001,22(3):204-206.Hu Chun-bo,He Guo-qiang,Liu Pei-jin,et al.Experimental study on slag accumulation in back wall region of SRM submerged nozzle[J].Journal of Propulsion Technology,2001,22(3):204-206.
[7]	向红军,方国尧.固体火箭发动机熔渣沉积数值模拟[J].推进技术,2002,23(5):366-369.Xiang Hong-jun,Fang Guo-yao.Numerical simulation of slag accumulation for solid rocker motors[J].Journal of Propulsion Technology,2002,23(5):366-369.
[8]	Xiao Yu-min,Amano R S.Velocity of particles on solid propellant surface[R].AIAA 2002-0640,2002.
[9]	魏超.固体火箭发动机潜入与非潜入喷管流场与粒子沉积研究[D].西安:航天动力技术研究院,2005.
[10]	周力行.湍流气粒两相流动和燃烧的理论与数值模拟[M].北京:科学出版社,1994:117-207.
[11]	Sabnis J S,Madabhushi R K.Simulation of flow and particle impingement patterns in titan IV SRM aft closure[R].AIAA 95-2879,1995.
[12]	Liaw P,Chen Y S,Shang H M,et al.Numerical investigation of the slag behavior in the aft-end cavity of solid rocket motors[R].AIAA 95-0815,1995.
[13]	Godfroy F,Guery J F.Unsteady eulerian two-phase flow analysis of solid rocket motor mlag[R].AIAA 97-2859,1997.
[14]	Cesco N,Dumas L,Hulin A,et al.Stochastic models to the investigation of slag accumulation in a large solid rocket motor[R].AIAA 97-3118,1997.
[15]	Chauvot J F,Dumas L,Schmeisser L.Modeling of alumna slag formation in solid rocket motors[R].AIAA 95-2729,1995.
[16]	Whitesides R H,Purinton D C.Effects of slag ejection on solid rocket motor performance[R].AIAA 95-2724,1995.
