提取流管实验装置中声衬声阻抗的模态方法

基金项目: 航空基金资助项目(03c51029);自然科学基金资助项目(10272015)

A mode match method for extracting impedance of liners in flow duct facility

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要: 发展了一种模态匹配方法进行有均匀流条件下敷设声衬的二维矩形流管中声传播的计算, 计算结果与NASA流管实验结果和CAA计算结果符合得很好.在此基础上, 着重介绍采用求极值的变尺度法优化目标函数和给定求解范围寻找目标函数最小值两种方法进行管内未知声阻抗的提取, 给出了算例验证, 并分析了随机误差和已知声压点数对计算结果的影响.
- 航空、航天推进系统 /
- 流管 /
- 模态匹配 /
- 声传播 /
- 声阻抗提取
Abstract: A mode-match method was developed for calculating the sound propagation in two-dimensional lined rectangular flow duct with uniform flow,the prediction results agree well with the data from NASA flow duct facility and CAA calculation.Based on these,an unknown impedance extracting is implemented by applying changed-scales method to optimize object function or by pursuing a minimum of object function in a given region.The two methods are validated by some cases and the effects of random error and the number of input pressure on the results are analyzed.
- aerospace propulsion system /
- flow duct /
- mode-match /
- sound propagation /
- impedance extracting

[1]	李晓锋,王同庆,史伟.声衬流动声性能测量的流管实验装置设计及调试[J].航空动力学报,2005,20(6):1 037-1 040.LI Xiaofeng,WANG Tongqing,SHI Wei.Design and adjustment of flow duct facility for acoustic liner measurement[J].Journal of Aerospace power,2005,20(6):1 037-1 040.
[2]	管莹,王同庆,王利.流管实验装置中声传播计算的模态方法[J].工程热物理学报,2006,27(4):595～597.GUAN Ying,WANG Tongqing,WANG Li.A mode matching method for calculating sound propagation in flow duct equipment[J].Journal of Engineering Thermophysics,2006,27(4):595～597.
[3]	Watson W R,Jones M G,Tanner S E and Parrott T L.A finite element propagation model for extracting eormal incidence impedance in nonprogressive acoustic wave fields[R].NASA TM 110160,April 1995.
[4]	Watson W R,Jones M G,Parrott T L.Validation of an impedance eduction method in flow[R].AIAA-98-2279.
[5]	Parrott T L,Watson W R,Jones M G.Experimental validation of a two-dimensional shear flow model for determining acoustic impedance[R].NASA TP-2679,1991.
[6]	Li X D,Thiele F.Numerical computation of sound propagation in lined ducts by time-domain impedance boundary conditions[R].AIAA 2004-2902
[7]	何光渝,高永利.Visual Fortran 常用数值算法集[M].北京:科学出版社,2002:508-513.
