面向对象的涡扇发动机及控制系统仿真平台

周文祥; 黄金泉; 窦建平; 沈峰

面向对象的涡扇发动机及控制系统仿真平台

南京航空航天大学能源与动力学院, 江苏南京 210016

计量
- 文章访问数: 1653
- HTML浏览量: 101
- PDF量: 463
- 被引次数: 0
出版历程
- 收稿日期: 2006-05-23
- 修回日期: 2006-10-13
- 刊出日期: 2007-01-28

Object-oriented simulation platform for turbofan engineand its control system

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 研究了面向对象的航空发动机数值仿真平台实现机理, 构建了涡扇发动机及其控制系统模型库, 采用面向对象方法完成了模型库及辅助类库的代码实现;研究了交互式仿真界面及模块化构建仿真系统的关键技术, 在此基础上结合模型库、辅助类库构建了涡扇发动机及其控制系统通用仿真平台, 仿真结果表明, 该平台可计算发动机从零加速到最大状态的全程实时动态仿真, 动态误差小于8%, 控制系统响应快, 超调小, 能够满足发动机控制仿真的需求.
- 航空、航天推进系统 /
- 仿真 /
- 控制系统 /
- 面向对象
Abstract: The method of developing object-oriented aeroengine numerical simulation platform is investigated.Basic class hierarchy for turbofan engine and control system performance simulation was designed.These basic classes together with some other assistant classes were coded through object-oriented computer language.The key technology for programming interactive graphical user interface and modular simulation system was introduced.A general numerical simulation platform for turbofan engine and control system was developed.Simulation results show that the platform can simulate turbofan engine dynamic process from near zero to maximal state,and the dynamic simulation error is less than 8%.The control system has quick response with suitable percent overshot.The platform is suitable for aeroengine and control system simulation.
- aerospace propulsion system /
- simulation /
- control system /
- object-oriented

HTML

参考文献(12)

[1]	Drummond C K,Follen G J,Putt C W.Gas turbine system simulation:an object-oriented approach[R].NASA-TM-106044.Lewis Research Center Cleveland:NASA.1992.
[2]	Curlett B P,Felder J L.Object-oriented approach for gas turbine engine simulation[R].NASA-TM-106970.Lewis Research Center Cleveland:NASA 1995.
[3]	Reed J A.Onyx.An objected-oriented framework for computational simulation of gas turbine systems[D].Toledo,USA:The University of Toledo,1998.
[4]	Visser W P J,Broomhead M J.GSP:A generic object-oriented gas turbine simulation environment[R].NLR-TP-2000-267,Holand:National Aerospace Laboratory NLR,2000.
[5]	Alejandro A.Modeling of a gas turbine with modelicaTM[D].Master Thesis,Department of Automatic Control,Lund Institute of Technology,Sweden:May 2001.
[6]	Turner M G,Norris A,Veres J P.High-fidelity three-dimensional simulation of the GE90[R].NASA TM-2004-212981,2004.
[7]	Turner M G,Reed J A,Ryder R,et al.Multi-fidelity simulation of a turbofan engine with results zoomed into mini-maps for a zero-D cycle simulation[R].NASA TM-2004-213076,2004.
[8]	唐海龙,张津.面向对象的航空发动机性能仿真程序设计方法研究[J].航空动力学报,1999,14(4):421-424.TANG Hailong,ZHANG Jin.A study of object-oriented approach for aeroengine performance simulation[J].Journal of Aerospace Power,1999,14(4):421-424.
[9]	唐海龙,张津.数据通信模式及其在面向对象的航空发动机性能仿真系统中的应用[J].航空动力学报,2000,15(3):298-302.TANG Hailong,ZHANG Jin.Data communication model and its application in object-oriented aeroengine simulation system[J].Journal of Aerospace Power,2000,15(3):298-302.
[10]	谢志武.面向对象的燃气轮机仿真研究[D].上海:上海交通大学,1998.XIE Zhiwu.Research on object-oriented gas turbine simulation[D].Shanghai:Shanghai Jiaotong University,1998.
[11]	窦建平,黄金泉,周文祥.基于UML的航空发动机建模研究[J].航空动力学报,2005,20(4):684-688.DOU Jianping,HUANG Jinquan,Zhou Wenxiang.Research of aeroengine modeling based on UML[J].Journal of Aerospace Power,2005,20(4):684-688.
[12]	周文祥,黄金泉,窦建平.涡扇发动机部件级起动模型[J].航空动力学报,2006,21(2):248-253.ZHOU Wenxiang,HUANG Jinquan,DOU Jianping.Development of component-level startup model for a turbofan engine[J].Journal of Aerospace Power,2006,21(2):248-253
