内部冲击和外部气膜的组合特性研究

丁水汀; 崔亮; 孙纪宁; 陶智; 徐国强; 李秋实

内部冲击和外部气膜的组合特性研究

北京航空航天大学能源与动力工程学院航空发动机气动热力重点实验室, 北京 100083

基金项目: 新世纪优秀人才支持计划资助(NCET-05-0189)

计量
- 文章访问数: 1560
- HTML浏览量: 151
- PDF量: 428
- 被引次数: 0
出版历程
- 收稿日期: 2006-01-17
- 修回日期: 2006-05-09
- 刊出日期: 2007-02-28

Combined features of the inner impingement and outer film cooling holes of a vane

National Key Laboratory on Aero-Engines, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要

摘要: 利用数值模拟的方法研究了一种外部稀疏气膜和内部冲击复合的导向器叶片冷却结构.研究的重点是气膜孔和冲击孔的相对位置以及气膜孔直径对叶盆和叶背冷却效率的影响规律, 并对叶盆区域和叶背区域的综合冷却效率和热均匀性做了讨论.计算表明:在计算所选取的参数范围内, 气膜孔直径的增大提高了叶盆区域的综合冷却效率, 而对叶背区域的影响规律则较为复杂;综合考虑叶盆叶背的冷却效率和热均匀性, 气膜孔的位置在单元腔的前部时冷却效果最好.
- 航空、航天推进系统 /
- 气膜冷却 /
- 冲击冷却 /
- 冷却效率 /
- 数值模拟
Abstract: Numerical simulation has been used to investigate a cooling configuration of a guide turbine vane.This vane has outer sparse film cooling holes and inner impingement holes.In this paper,we mainly studied how different positions and diameters of the film cooling holes influenced the cooling efficiency on the pressure and suction sides of the vane;and discussed the cooling efficiency and uniformity of temperature distribution on the pressure and suction sides of the vane.The computational results show that,within the parameters used in this simulation,the increase in the film cooling hole diameters obviously improves the cooling efficiency on the pressure side of the vane,but the effect is more complicated on the suction side.Considering the cooling efficiency and the uniformity of temperature distribution on the pressure and suction sides of the vane,the position of the film cooling holes located on the front side of the chamber results in the best cooling efficiency.
- aerospace propulsion system /
- film cooling /
- impingement cooling /
- cooling efficiency /
- numerical simulation

HTML

参考文献(6)

[1]	Thomas M C.Allison manufacturing,property and turbine engine performance of CMSX-4R single crystal airfoils[R].Allison Engine Company,1994.
[2]	Haley P J.The gas turbine of the furture[R].Rolls-Royce Corporation,2004.
[3]	郁新华,全栋梁,刘松龄,等.层板结构冷却有效性的研究[J].航空动力学报,2003,18(5):615-622.YU Xinhua,QUAN Dongliang,LIU Songling,et al.Investigation of the cooling effectiveness of lamilloy[J].Journal of Aerospace Power,2003,18(5):615-622.
[4]	全栋梁,刘松龄,李江海.层板冷却结构传热优化数值模拟研究[J].西北工业大学学报,2004,22(6):816-820.QUAN Dongliang,LIU Songling,LI Jianghai.Numerical investigation on optimizingheat transfer in lamilloy[J].Journal of Northwestern Polytechnical University,2004,22(6):816-820.
[5]	陶文铨.数值传热学[M].第2版.西安:西安交通大学出版社,2001.
[6]	曹玉璋,陶智,徐国强,等.航空发动机传热学[M].北京:北京航空航天大学出版社,2005.
