多循环脉冲爆震发动机工作过程中的延迟时间研究

张义宁; 王家骅; 刘鸿; 张靖周

多循环脉冲爆震发动机工作过程中的延迟时间研究

1.
南京航空航天大学能源与动力学院南京 210016
2.
江苏工业学院机械工程系, 常州 213016

基金项目: 国防基础预研项目(K1600060704)

计量
- 文章访问数: 1578
- HTML浏览量: 4
- PDF量: 425
- 被引次数: 0
出版历程
- 收稿日期: 2006-01-04
- 修回日期: 2006-03-27
- 刊出日期: 2007-02-28

Investigation of several delay times in operation process of multi-cycle pulse detonation engine

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
Jiangsu Polytechnic University, Changzhou 213016, China

摘要

摘要: 为了提高两相脉冲爆震发动机(PDE)工作的协调性, 运用离子传感器、动态压力传感器, 对爆震燃烧的几个延迟时间以及供油电磁阀工作性能进行研究.研究表明:以汽油为燃料、空气为氧化剂的气动阀式PDE, 点火延迟时间为3.0-4.5 ms, 气动阀关闭滞后点火信号发出4.9-6.4 ms, 供油电磁阀开、关延迟分别为2.4ms和3.4 ms左右.缓燃向爆震转捩时间为3.0-3.8 ms.PDE工作频率大于20 Hz时, 电磁阀不能按设定时间工作.研究成果对PDE工作过程的协调及有效控制具有参考价值.
- 航空、航天推进系统 /
- 脉冲爆震发动机(PED) /
- 延迟时间 /
- 控制 /
- 气动阀
Abstract: In order to promote the operating coordination of a two-phase pulse detonation engine(PDE),the delay time of detonation and operating performance of the solenoid valve were experimentally studied by using ion-sensors and pressure transducers of high-frequency response.The detonation tube is of 58mm inner diameter and 1 270 mm long.Liquid gasoline/air mixture is filled for the engine multi-cycle operations.According to the research,the mixture ignition delay is 3～4.5 ms,the aero-valve closing delay is 4.9～6.4 ms,and the solenoid electric valve on/off delay time is 2.4 ms and 3.4 ms respectively.The transition time from deflagration-to-detonation is about 3.0～3.8 ms.The solenoid electric valve cannot operate orderly when the engine operating frequency is higher than 20 Hz.These data obtained are helpful to coordinate PDE operation process.
- aerospace propulsion system /
- pulse detonation engine(PDE) /
- delay time /
- control /
- aero-valve

HTML

参考文献(11)

[1]	Goracke D B,Levack D J H.Tripropellant engine drive cycle considerations for the SSTO application[R].AIAA95-2950.
[2]	Manski D,Goertz C,Sassnick H,et al.Cycles for earth-to-orbit propulsion[J].Journal of Propulsion and Power.1998,14(5):588-604.
[3]	Colasurdo G,Pastrone D,Casalino L.Optimal performance of a dual-fuelsingle-stage rocket[J].Journal of Spacecraft and Rockets,1998,35(5):667-671.
[4]	Chao T W,Wintenberger E,Shepherd J E.On the design of pulse detonation engines[R].GALCIT Report FM00-7,2001.
[5]	Bussing T R A,Bratkovich T E,Hinkey Jr J B.Practical implementation ofpulse detonation engines[R].AIAA 97-2748.
[6]	Kentfield J A C.The potential of valveless pulsejets for small UAV propulsion applications[R].AIAA 98-3879
[7]	Cooper M,Jackson S,shepherd J E.Effect of deflagration-detonation transition on pulse detonation engine impulse[R].CALCIT Report FM00-3,2000.
[8]	范育新,王家骅,李建中,等.脉冲爆震发动机工作过程控制和协调试验[J].推进技术,2004,25(6):538-542.FAN Yuxin,WANG Jiahua,LI Jianzhong,et al.Experimental investigation on working process of pulse detonation engine (PDE)[J].Journal of Propulsion Technology,2004,25(6):538-542.
[9]	张义宁,王家骅,张靖周.频率30～50Hz两相脉冲爆震发动机研究.航空学报2006,27(6):993-997.ZHANG Yining,WANG Jiahua,ZHANG Jingzhou,Investigation on two phase pulse detonation engine at the frequency 30～50Hz[J].Acta Aeronautica et Astronautica Sinica,2006,27(6):993-997.
[10]	范育新,王家骅,李建中,等.脉冲爆震发动机供油自适应控制优化设计研究[J].推进技术,2005,26(1):62-67.FAN Yuxin,WANG Jiahua,LI Jianzhong,et al.Mechan-ism of fuel self-fit control in pulse detonation engine[J].Journal of Propulsion Technology,2005,26(1):62-67.
[11]	张义宁,王家骅,张靖周.两相多循环爆震波特性研究[J].航空动力学报,2006,21(5):789-794.ZHANG Yining,WANG Jiahua,ZHANG Jingzhou.Investigation on two-phase and multi-cycle detonation[J].Journal of Aerospace Power,2006,21(5):789-794.
