可扩展的推进系统仿真平台:部分Ⅰ-工程模型构建
An extensible propulsion simulation platform Part I-foundations of engineering model
-
摘要: 基于java的面向对象建模, 建立了可扩展的推进系统仿真平台(EPSP).研究了EPSP中分级模型建立的机制;基于组件分解和标准化接口, 提出了EPSP中所用的工程模型架构的设计.EPSP允许部件被其它类似功能的部件替换, 用户可以自己组建推进系统模型, 并进行各学科和各精度的仿真计算.如何构建EPSP的工程模型将被描述, 文中给出了部件工程模型创建的示例, 表明可以利用本平台很方便的架构推进系统模型, 体现了“插件化”的思想, 证明本平台的建模达到了预期的目标.Abstract: EPSP(extensible propulsion simulation platform) was developed as a Java-based object-oriented platform for propulsion system simulation.The architecture represents the hierarchal structure of the engine,its components and substructures using recursive composition.This paper presents the design of a common engineering model framework for use in EPSP.This technique provides an access to build models with increasingly complex elements out of simpler ones.The foundations of the platform's engineering model were described.To test the platform,we can easily construct a component based engineering model,and the "pluggability" of the architecture is shown.The example proves the validity and feasibility of the modeling of the platform.
-
[1] Reed J A,Afjeh A A.Computational simulation of gas turbines:part I-foundations of component-based models[R].International Gas Turbine & Aeroengine Congress & Exhibition,1999. [2] 唐海龙,张津.面向对象的航空发动机性能仿真程序的设计方法研究[J].航空动力学报,1999,14(4):421-424.TANG Hailong,ZHANG Jing.A study of object-oriented approach for aeroengine performance simulation[J].Journal of Aerospace Power,1999,14(4):421-424. [3] 陈策,王文栋,李军.面向对象的发动机特性计算的建模与仿真[J].机械科学与技术,2003,7月(增刊):34-36.CHEN Ce,WANG Wen dong,LI Jun.An object-oriented modeling and simulation of turbofan characteristic[J].Mechanical Science and Technology,2003,7:34-36. [4] Visser W P J,Broomhead M J.A generic object-oriented gas turbine simulation environment[R].ASME Turbo Expo 2000,Munich,Germany,8211May 2000. [5] Reed J A,Afjeh A A.Computational simulation of gas turbines[R].In:International gas turbine &Aeroengine Congress & Exhibition,Indianapolis,Indiana,USA,June 7-10,1999,1-11. [6] Bayt R L,Sahm M K,Lents C E.Collaborative engineering in integrated aircraf t power system design[R].ASME 2002 Design Engineering Technical Conferences and Computers and Information in Engineering Conference,Montreal,Canada,September 29-October 2,2002.
