涡轮叶片榫齿部位疲劳/蠕变试验的新特点
New characteristics of fatigue-creep tests on serration of turbine blades
-
摘要: 在某型航空发动机涡轮叶片的低周疲劳试验中发现, 叶片疲劳/蠕变试验寿命高于纯疲劳试验寿命, 为探究这一现象的原因, 对此展开相关的理论计算和分析.研究表明:试验条件较好地模拟了叶片的实际工作条件, 该涡轮叶片的损伤以疲劳损伤为主, 相对于真实涡轮叶片的纯疲劳试验, 在疲劳/蠕变试验条件下, 其考核部位(榫齿)出现了较大的应力松弛, 故而使得叶片疲劳/蠕变寿命高于纯疲劳寿命.研究结果对于保证发动机安全工作、提高飞行可靠性、以及发展高温构件的疲劳试验技术有重要意义.Abstract: The fatigue-creep life was found to be longer than the fatigue life from the Low Cycle Fatigue experiment of turbine blade of an aeroengine.The relevant theoretical calculation and analysis were then carried out to provide a further insight into such phenomenon.The research shows that: the actual working conditions of blades were well simulated in the experimental conditions,indicating that the damage of blade was mainly attributable to fatigue damage.As compared with pure fatigue test of real turbine blade,stress relaxation occurred at the key section(serration) under fatigue-creep test conditions,showing that fatigue/creep life of blade was longer than fatigue life.The research results play a key role in ensuring the safety of engines,improving the flight reliability and developing fatigue test techniques of high-temperature components.
-
[1] Issler S,Eberhard R.Numerical and experimental investigations into life assessment of blade-disc connections of gas turbines[J].Nuclear Engineering and Design,2003,226:155-164. [2] 闫晓军,聂景旭.定向结晶涡轮叶片蠕变/疲劳寿命的试验与分析[J].航空动力学报,2005,20(6):925-931.YAN Xiaojun,NIE Jingxu.New experimental approach in determining creep/fatigue life of directionally solidified alloy turbine Blade[J].Journal of Aerospace Power,2005,20(6):925-931. [3] 王正,刘蔚.蠕变-疲劳交互作用对高温低周疲劳寿命的影响[J].石油化工设备,2003,32(4):1-4.WANG Zheng,LIU Wei.Creep-fatigue interaction on fatigue life under high-temperature[J].Petro-Chemical Equipment,2003,32(4):1-4. [4] 张可.某型涡轮叶片的强度分析[D].北京:北京航空航天大学,2004. [5] 黄志豪,马翠娣,王庆如,等.材料数据手册[M].北京:北京航空材料研究所,1993:573-585. -
