宽弦空心风扇叶片动力响应特性研究

杨雯; 杜发荣; 郝勇; 丁水汀; 李秋实; 王营

宽弦空心风扇叶片动力响应特性研究

1.
北京航空航天大学航空发动机气动热力重点实验室, 北京 100083
2.
沈阳发动机设计研究所, 沈阳 110015

基金项目: 新世纪优秀人才支持计划资助(NCET-05-0189)

计量
- 文章访问数: 1446
- HTML浏览量: 1
- PDF量: 454
- 被引次数: 0
出版历程
- 收稿日期: 2006-02-09
- 修回日期: 2006-06-14
- 刊出日期: 2007-03-28

Investigation of dynamic response property of wide-chord hollow fan blade

1.
National Key Laboratory on Aero-Engines, Beijing University of Aeronautics and Astronautics, Beijing 100083, China
2.
Shengyang Aeroengine Research Institute, Shenyang 110015, China

摘要

摘要: 宽弦空心风扇叶片是未来风扇叶片的发展趋势.本文采用ANSYS软件利用数值模拟方法, 通过对叶片的模态特性和脉冲激励下的响应特性研究得到了叶片的基本变形以及动态响应变形情况.结论为该风扇叶片振动时以弯曲变形为主, 工作转速在6000r/min以内, 弯曲振动变形规律以及叶片空心加芯板的结构决定了叶片应力集中发生在内含芯板的叶盆中心处.另外, 在叶片高速旋转时的离心作用使得叶根处也成为应力集中区域.
- 航空、航天推进系统 /
- 宽弦空心风扇叶片 /
- 模态 /
- 变形 /
- 动态响应
Abstract: Wide-chord hollow fan blade is the trend of future development.By means of numerical simulation,basic deformations and deformations under dynamic response were investigated through the analysis of mode characteristic and the study of dynamic response characteristic under the pulsed excitation.Results show that the blade mainly has flexural deformation as the blade vibrating,and the rotating speed of the blade must be within 6 000 rpm.The flexural vibratory deformation regulation and the structure of hollow with core board decide that the stress concentration should occur in somewhere of the center of blade basin with core board.In addition,the root of blade become into the area of stress concentration with the effect of centrifugal force under the blade's high rotating speed.
- aerospace propulsion system /
- wide-chord hollow fan blade /
- mode /
- deformation /
- dynamic response

HTML

参考文献(4)

[1]	蒋孝煜.有限元法基础[M].北京:清华大学出版社,1992.
[2]	陈伟,宋迎东,尹晶,等.离心载荷作用下平板叶片鸟撞击响应计算[J].航空动力学报,1997,12(2):122-126.CHEN Wei,SONG Yingdong,YIN Jing,et al.Numerical analysis of blade transient response to impact under centrifugal loading[J].Journal of Aerospace Power,1997,12(2):122-126.
[3]	李晓雷,俞德孚,孙逢春.机械振动基础[M].北京:北京理工大学出版社,1996.
[4]	赵海峰,蒋迪.ANSYS8.0工程结构实例分析[M].北京:中国铁道出版社,2004.
