弯曲及局部修型对大折转角扩压叶栅性能的影响

李绍斌; 苏杰先; 冯国泰; 王仲奇

弯曲及局部修型对大折转角扩压叶栅性能的影响

哈尔滨工业大学能源科学与工程学院, 哈尔滨 150001

基金项目: 国家自然科学基金重点项目资助(50236020)

计量
- 文章访问数: 1355
- HTML浏览量: 2
- PDF量: 466
- 被引次数: 0
出版历程
- 收稿日期: 2006-03-09
- 修回日期: 2006-05-22
- 刊出日期: 2007-03-28

Effect of blade bowing and local modification on high-turning angle compressor stator performance

School of Energy Science and Engineering, Harbin Institute of Technology, Harbin 150001, China

摘要

摘要: 通过数值模拟对具有51°叶型折转角的环形扩压叶栅进行了研究.将外流飞行器上控制附面层流动的基本思想和修型措施应用于弯叶片的局部修型, 结合近壁面附面层流动和总压损失对比分析了大折转角扩压叶栅采用直叶片、弯叶片和局部修型弯叶片的气动性能.结果表明:在大折转角、高亚声速气流进口条件下, 局部修型弯叶片能更有效的控制大逆压梯度下叶栅内附面层的发展, 提高叶栅气动性能.
- 航空、航天推进系统 /
- 大折转角 /
- 局部修型 /
- 扩压叶栅 /
- 弯叶片
Abstract: This paper presents a numerical study of a high-turning angle compressor stator with 51°.The main ideas and local modification to achieve better control of boundary layer flow in aircraft are applied to the contouring of bowed stator.The skin friction line of suction side and total pressure loss are discussed in the straight blade,bowed blade and local modified bowed blade.The results show that the local modified bowed blade can effectively control the boundary layer flow and it is applicable to the boundary conditions of high adverse pressure gradient,high-turning and high subsonic inlet velocity.
- aerospace propulsion system /
- high-turning angle /
- local modification /
- compressor stator /
- bowed blade

HTML

参考文献(9)

[1]	Bryce J D,Cherrett M A,Lyes P A.Three-dimensional flow in a highly loaded single-stage transonic fan[J].ASME Journal of Turbomachinery,1995,117:22-28.
[2]	Emmerson P R.Three-dimensional flow calculations of the stator in a highly loaded transonic fan[R].ASME Paper 96-GT-546,Birmingham,1996.
[3]	Calvert W J,Emmerson P R,Moore J M.Design,test and analysis of a high-Pressure-ratio transonic Fan[R].ASME Paper GT2003-38302,Atlanta,2003.
[4]	Friedrichs J,Baumgarten S,Kosyna G,et al.Effect of stator design on stator boundary layer flow in a highly loaded single-stage axial-flow low-speed compressor[R].ASME Paper 2000-GT-616,Munich,2000.
[5]	Boese M,Fottner L.Effects of riblets on the loss behavior of a highly loaded comperssor cascade[R].ASME Paper GT-2002-30438,Amsterdam,2002.
[6]	Douglas J W,Li S M,Song B,et al.Effects of freestream turbulence on the losses of a highly loaded comperssor stator blade[R].ASME Paper GT2003-38604,Atlanta,2003.
[7]	Hilgenfeld L,Pfitzner M.Unsteady boundary layer development due to wake passing effects on a highly loaded linear comperssor cascade[R].ASME Paper GT2004-53186,Vienna,2004.
[8]	刘宝杰,邹正平,严明,等.叶轮机计算流体动力学技术现状与发展趋势[J].航空学报,2002,23(5):394-404.LIU Baojie,ZOU Zhengping,YAN Ming,et al.Present status and future development of CFD in turbomachinery[J].Acta Aeronautic et Astronatica Sinica,2002,23(5):394-404.
[9]	夏雪湔,邓学蓥.工程分离流动力学[M].北京:北京航空航天大学出版社,1991:242-254.
