尾缘吹气稳定器初始雾化场实验及对燃烧计算的改进

马文杰; 张羽; 杨阳; 樊未军; 杨茂林

尾缘吹气稳定器初始雾化场实验及对燃烧计算的改进

北京航空航天大学能源与动力工程学院, 北京 100083

计量
- 文章访问数: 1520
- HTML浏览量: 2
- PDF量: 533
- 被引次数: 0
出版历程
- 收稿日期: 2006-04-20
- 修回日期: 2006-07-05
- 刊出日期: 2007-05-28

Experimental study on initial spray field of EBMC flame holder and the improvement in the numerical simulation of combustion

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要

摘要: 利用激光测雾仪(PDA)对尾缘吹气式火焰稳定器尾缘出口的初始雾化场进行了实验研究, 在静止空气中测量了尾缘出口下游不同截面上的各点处的液滴直径、速度等参数, 分析了雾化场结构, 初步探讨了初始雾化场的特征.同时, 根据初始雾化场的实验结果给出燃烧数值模拟的初始雾化条件, 并把计算结果与燃烧实验数据和经验数值计算结果进行对比, 分析了实验初始雾化场数据对燃烧数值计算的改进效果.结果表明, 初始雾化场实验数据对燃烧室出口温度分布及燃烧效率的计算, 都有一定程度的改进, 其中对燃烧效率计算的改进效果更为明显.
- 航空、航天推进系统 /
- 火焰稳定器 /
- 尾缘吹气 /
- 雾化 /
- 数值计算
Abstract: An experimental study on initial spray field of edge blowing mixture curtain(EBMC) flame holder was conducted using a particle dynamics analyzer(PDA).The droplet diameter and velocity of the spray were measured downstream of the flame holder at different locations in static air.The feature of initial spray field was analyzed.The initial spray conditions for the numerical simulation of combustion was given based on the experimental results of initial spray field.The calculated results were compared with the experimental data and the empirical calculated data.The results indicate that the application of initial spray field experimental data to the numerical combustion simulation improves the calculated results of temperature distribution and combustion efficiency,and the improvement in the calculation of combustion efficiency is especially obvious.
- aerospace propulsion system /
- flame holder /
- edge blowing mixture curtain(EBMC) /
- atomization /
- numerical simulation

HTML

参考文献(5)

[1]	杨茂林,全中,白兴艳,等.尾缘吹气式火焰稳定器试验研究[J].航空动力学报,1998,13(2):185-188.YANG Maolin,QUAN Zhong,BAI Xingyan,et al.Experimental Investigation on EBMC flameholder[J].Journal of Aerospace Power,1998,13(2):185-188.
[2]	岳连捷,杨茂林,黄勇,等.尾缘吹气式火焰稳定器流场计算[J].航空动力学报,1998,13(2):180-184.YUE Lianjie,YANG Maolin,HUANG Yong,et al.Numerical prediction of cold flow field behind EBMC flameholder[J].Journal of Aerospace Power,1998,13(2):180-184.
[3]	YUE Lianjie,LIU Baojie,XIONG Jianqiu,et al.Experimental study on cold flow field behind the EBMC flameholder by PIV[R].Fifth CAE-NAL Workshop,Advanced Gas Turbine Technologies,1999.
[4]	岳连捷,熊建秋,樊维均,等.尾缘吹气式火焰稳定器燃烧性能研究[J].航空动力学报,2001,16(4):345-349.YUE Lianjie,XIONG Jianqiu,FAN Weijun,et al.Research on combustion performance of the edge blowing mixture curtain flameholder[J].Journal of Aerospace Power,2001,16(4):345-349.
[5]	《航空发动机设计手册》总编委会编.《航空发动机设计手册》第9册主燃烧室[M].北京:航空工业出版社,2000.
