T300/BMP-316复合材料板冲击损伤研究

Research on impact damage of T300/BMP-316 composite laminates

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要: 采用自由落体冲击设备, 对两种不同尺寸不同铺层顺序的T300/BMP-316复合材料层合板进行了详细的低速冲击损伤试验研究, 同时应用作者以前发展的复合材料层合板逐渐累积损伤分析方法对层板的冲击过程进行了模拟.结果表明, 几何尺寸对层合板的冲击损伤投影面积有较大的影响, 而铺层顺序对冲击损伤投影面积影响不大, 但对层合板的冲击损伤形状会有一定的影响.
- 航空、航天推进系统 /
- 低速冲击 /
- 复合材料层合板 /
- 损伤
Abstract: The experimental research of low speed impact damage has been carried out on composite laminates with different geometries and layer direction angle,and the impact process was simulated by the progressive damage method.The geometries of composite laminates have much effect on the impact damage projected area.The layer direction angle of composite laminates has little effect on the impact damage projected area,but it has influence on the impact damage figure.
- aerospace propulsion system /
- low speed impact /
- composite laminates /
- damage

[1]	Chuks N O,David C W,Finite-element modeling of the impact response of a laminated composite plate[J].Compos Sci Technol,1999,59:1913-1922.
[2]	Corum J M,Battiste R L,Wrenn M B R.Low-energy impact effects on candidate automotive structural composites[J].Compos Sci Technol,2003,63:755-769.
[3]	Christoforou A P.Impact dynamics and damage in composite structures[J].Composite structures,2001,52:181-188.
[4]	Johnson A F,Holzapfel M.Modeling soft body impact on composite structures[J].Composite structures,2003,61:103-113.
[5]	Schoeppner G A,Abrate S.Delamination threshold loads for low velocity impact on composite laminates[J].Composites:Part A,2000,31:903-915.
[6]	Johnson A F.Modeling fabric reinforced composites under impact loads[J].Composites:Part A,2001,32:1197-1206.
[7]	赵渠森.先进复合材料手册[M].北京:机械工业出版社出版,2003.
[8]	徐颖,温卫东,崔海坡.复合材料层合板低速冲击逐渐累积损伤预测方法[J].材料科学与工程学报,2006,24(1):77-81.XU Ying,WEN Weidong,CUI Haipo.A cumulative damage prediction method of low-velocity impacts on laminated composites[J].Journal of Materials Science Engineering,2006,24(1):77-81.
[9]	Hou J P,Petrinic N,Ruiz C,et al.Prediction of impact damage in composite plates[J].Compos Sci.Technol,2000,60:273-281.
