提高三维ICT成像空间分辨率的扫描方式及其重建算法

魏东波; 傅健; 李斌; 张磊

提高三维ICT成像空间分辨率的扫描方式及其重建算法

北京航空航天大学机械工程及自动化学院, 北京 100083

基金项目: 国家自然科学基金资助项目(50575015,60502020)

计量
- 文章访问数: 1391
- HTML浏览量: 1
- PDF量: 473
- 被引次数: 0
出版历程
- 收稿日期: 2007-01-19
- 修回日期: 2007-04-02
- 刊出日期: 2007-05-28

Scan mode and its reconstruction algorithm for improving spatial resolution of 3D-ICT

School of Mechanical Engineering and automation, Beijing University of Aeronauticsand Astronautics, Beijing 100083, China

摘要

摘要: 对三维工业计算机层析成像(Three Dimensional Industrial Computed Tomography, 3D-ICT)空间分辨率提高技术进行了研究, 提出了一种通过1/4面阵探测器偏置扫描提高成像空间分辨率的锥束3D-ICT扫描方式, 推导了它的基于平行束重排的滤波反投影重建算法.这种方法首先通过面阵探测器中心相对于旋转中心偏移四分之一个探测单元宽度的扫描结构获取二维投影序列, 再对其进行平行束投影重排, 最后利用平行射束特点实现投影水平方向采样频率加倍, 从而提高3D-ICT水平方向的重建空间分辨率.计算机仿真结果证明了该扫描方式和重建算法的正确性.利用该种方法, 可使3D-ICT水平方向重建空间分辨率提高近1倍.
- 航空、航天推进系统 /
- 计算机层析成像 /
- 锥束扫描 /
- 空间分辨率 /
- 滤波反投影重建算法
Abstract: Spatial resolution improvement techniques for three dimensional industrial computed tomography(3D-ICT) have been researched in this paper.A cone-beam 3D-ICT scan mode was proposed to improve the spatial resolution by the quarter-detector offset.Its filter back-projection reconstruction algorithm based on the parallel beam rebin principle was deduced.Firstly this method acquires the two dimensional projection sequence by offsetting the detector center a quarter of the detector channel width with respect to the iso-center.Secondly it rebins these projects into parallel data.Finally it doubles the sampling frequency of parallel data with the symmetry between two projection view angles with an angle interval 180°.Computer simulation results prove the correction and the validity of this algorithm.Using this algorithm,the spatial resolution can be improved approximate 100% along the horizontal reconstruction direction.
- aerospace propulsion system /
- computed tomography /
- cone-beam scan /
- spatial resolution /
- filter back-projection reconstruction algorithm

HTML

参考文献(9)

[1]	程云勇,张定华,赵歆波,等.涡轮叶片锥束体积CT检测软件原型[J].中国机械工程,2005,16(20):1835-1838.CHENG Yunyong,ZHANG Dinghua,ZHAO Xinbo,et al.Software prototype of the turbine blade cone-beam volume CT inspection system[J].China Mechanical Engineering,2005,16(20):1835-1839.
[2]	程云勇,张定华,毛海鹏,等.一种基于工业CT的航空发动机涡轮叶片生产检测系统关键技术研究[J].制造技术与机床,2004(1):27-30.CHENG Yunyong,ZHANG Dinghua,MAO Haipeng,et al.Research on key techniques of inspection system for aero-engine turbine blade based on industrial CT[J].Manufacturing Technology and Machine Tool,2004,(1):27-30.
[3]	Hsieh J.Computed tomography-principles,designs,artifacts,and recent advances[M].Bellingham,WA:SPIE,2003.
[4]	Hsieh J.Optimization of detector geometry for aliasing artifact reduction in the third-generation CT[J].SPIE Vol.3032:204-212,1997.
[5]	Lonn A H.Comuted tomography system with translatable focal spot[P].USA:5173852,1990.
[6]	Kachelrieβ M.CT basics from single-slice to cone-beam spiral CT[EB/OL].http:www.imp.uni-erlangen.de,2005.
[7]	张朋,郭明焕.由相叠的低分辨率扇形束投影数据重建高分辨率CT图像[J].核技术,2002,25(10):805-810.ZHANG Peng,GUO Minghuan.Reconstructing high resolution image from overlapped low resolution fan beam projections data[J].Nuclear Techniques,2002,5(10):805-810.
[8]	Keat N.Understanding imaging performance(I)-spatial resolution and Z-sensitivity[EB/OL].http:www.imp.uni-erlangen.de,2005.
[9]	FU Jian,LU Hongnian.Research of large field of view scan mode for industrial CT[J].Chinese Journal of Aeronautics,2003,16(1):59-64.
