镍基单晶合金气冷叶片模拟试样的蠕变性能研究

卿华; 江和甫; 温卫东; 吴长波; 孙景国

镍基单晶合金气冷叶片模拟试样的蠕变性能研究

1.
南京航空航天大学能源与动力学院, 南京 210016
2.
中国燃气涡轮研究院强度研究室, 成都 610500

计量
- 文章访问数: 1578
- HTML浏览量: 0
- PDF量: 453
- 被引次数: 0
出版历程
- 收稿日期: 2006-04-14
- 修回日期: 2006-08-10
- 刊出日期: 2007-05-28

Study on the creep behavior of model specimens of nickel-based single crystal air-cooled blades

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
Department of Strength, Gas Turbine Establishment of China, Chengdu 610500, China

摘要

摘要: 对带孔和不带孔的某第二代镍基单晶合金平板试样进行了蠕变性能试验研究与有限元对比计算.高温蠕变试验表明, 平板试样的晶体取向和是否开孔对蠕变寿命有明显的影响.气膜孔导致蠕变寿命的降低, 对[001]取向的影响大于[111]取向.在高温低应力条件下, [001]取向的蠕变性能要优于[111]取向.有限元分析结果表明, 气膜孔改变了试样中的应力分布, 在孔附近产生了高应力, 导致模拟试验蠕变寿命的降低.有限元计算蠕变持久寿命与试验结果吻合, 说明采用基于分切应力的蠕变持久寿命计算模型是合理的.
- 航空、航天推进系统 /
- 镍基单晶 /
- 气冷叶片 /
- 蠕变 /
- 寿命
Abstract: Plate specimens were used to model turbine blades with cooling holes.Experimental and numerical study on the creep behavior of a second generation nickel-based single crystal alloy has been performed with these model specimens.The results of creep test at high temperature show that crystallographic orientations and cooling holes have noticeable influence on the creep life.Compared with that of the specimen without cooling holes,the creep life of specimen with cooling holes is lower for both and orientations.The cooling holes have larger influence on the creep life of orientation than that of orientation.The creep behavior under high temperature and low stress conditions of orientation is better than that of orientation.The finite element analysis(FEA) results reveal that the cooling holes change the stress distribution in the specimen and cause stress concentration near the holes,which results in the decrease of creep life.As the creep life obtained from FEA is accordant to the experimental result,it is reasonable to calculate the creep life using the simulation model based on the resolved slip stress.
- aerospace propulsion system /
- nickel-based single crystal /
- air-cooled blade /
- creep /
- life

HTML

参考文献(9)

[1]	尹泽勇,岳珠峰,杨治国,等.各向异性单晶合金结构强度与寿命[M].北京:国防工业出版社,2003.
[2]	Feleury G,Schubert F,Nickel H.Modelling of the thermal-mechanical behaviour of the single crystal superalloy CMSX-4[J].Computational Materials Science,1996,7:183-193.
[3]	Zhou H,Harada H,Koizumi Y,et al.Thermo-mechanical fatigue properties of a third generation single crystal superalloy TMS-75[R].High Temperature Materials 21,TMS Annual Meeting,Feb.2002,203-215.
[4]	Eggeler G.Final progress report,predictive microstructural assessment and micromechanical modelling of deformation and damage accumulation in single crystal gas turbine blading[R].MICROMOD,Brite/Euro 96-3911,Jan,2001.
[5]	于庆民,岳珠峰.晶体率相关弹塑性晶体滑移有限元程序[R].西安:西北工业大学报告,2005.
[6]	何明辉,李海燕,聂景旭.DD6单晶合金的高温蠕变/疲劳损伤研究[J].燃气涡轮试验与研究,2002,15(2):24-27.HE Minghui,LI Haiyan,NIE Jingxu.An investigation on creep/fatigue damage characteristics of single-crystal DD6 at high temperature[J].Gas Turbine Experiment and Research,2002,15(2):24-27.
[7]	于庆民.基于晶体塑性理论的镍基单晶合金构件力学性能的有限元分析[D].西安:西北工业大学,2005.
[8]	于庆民,万建松,岳珠峰.镍基单晶合金涡轮叶片蠕变分析的MARC用户子程序开发[J].燃气涡轮试验与研究,2004,17(4):20-23.YU Qingmin,WAN Jiansong,YUE Zhufeng.Development of MARC user subroutine for creep analysis of nickel-based single crystal blade[J].Gas Turbine Experiment and Research,2004,17(4):20-23.
[9]	岳珠峰,吕震宙.双剪切试样在镍基单晶合金蠕变变形损伤和寿命研究中的应用[J].金属学报,2002,38(8):809-813.YUE Zhufeng,LU Zhenzhou.Application of the double shear specimens in the study of the creep domage and rupture of the nickle-base single crystal superallays[J].Acta Metallurgice Sinice,2002,38(8):809-813.
