三单元气氢/气氧塞式喷管发动机实验
Tests on GH2/GO2 engine of 3-cell aerospike nozzle
-
摘要: 以气氢/气氧为推进剂, 对三单元直排塞式喷管模型发动机(内喷管和燃烧室内衬采用耐烧蚀材料钨渗铜, 塞锥为碳钢)进行了热试实验研究.给出了实验结果, 进行了数据分析.在两个压比(燃烧室压强与环境反压之比)下, 获得了塞式喷管性能数据和塞锥表面5个测点处的压强分布.实验表明, 塞式喷管具有良好的高度补偿能力和较高的效率.在压比值为50附近, 效率达到92%-93.5%;在压比值为350附近, 效率达到95%-96%.数值模拟的预示结果与实验数据吻合较好.Abstract: Hot-firing tests were carried out on a 3-cell GH2/GO2 linear aerospike nozzle engine with round-to-rectangle primary nozzles.The primary nozzles and inner layer of the combustion chambers were made of ablation-resistant W-Cu alloy and the aerospike ramp was made of steel.Data measured in the tests and data analyses were presented.The aerospike nozzle performance and pressure at five locations along aerospike ramp were obtained under two NPR(nozzle pressure ratio),which is the ratio of combustion chamber pressure to ambient pressure.It is shown that test aerospike nozzle has good altitude compensability of thrust.High nozzle thrust efficiencies were yielded in the tests.Near NPR value of 50,nozzle efficiency was 92% to 93.5% and nozzle efficiency is 95% to 96% near NPR value of 350.Numerically predicted results are in good agreements with test data.
-
Key words:
- aerospace propulsion system /
- rocket engine /
- aerospike nozzle /
- hot-firing test /
- performance
-
[1] Ryan H M,Solano W,Holland R,et al.The future of full-scale propulsion testing[R].AIAA Paper 2001-0746,2001. [2] Onofri M.Plug nozzles:summery of flow features and engine performance[R].AIAA Paper 2002-0584,2002. [3] Sakamoto H,Takahashi M,Sasaki M,et al.An experimental study on a 14 kN linear aerospike nozzle combustor[R].AIAA Paper 99-2761,1999. [4] 王长辉.塞式喷管气动特性的实验和数值模拟研究[D].北京:北京航空航天大学,2005.WANG Changhui.Experimental and numerical investigation of aerospike nozzle aerodynamic characteristics[D].Beijing:Beijing University of Aeronautics and Astronautics,2005. [5] Mori H,Taniguchi M,Nishihira R,et al.Experimental analyses of linear-type aerospike nozzles with and without sidewalls[R].AIAA Paper 2005-1350,2005. [6] 覃粒子,刘宇,王一白.塞式喷管多参数性能优化计算[J].宇航学报,2002,23(2):28-33.QIN Lizi,LIU Yu,WANG Yibai.Optimized performance calculation in multi-parameter for aerospike nozzle[J].Journal of Astronautics,2002,23(2):28-33. [7] 丘哲明,陈明义,杨传荣,等.固体火箭发动机材料与工艺[M].北京:宇航出版社,1995:135-136.QIU Zeming,CHEN Mingyi,YANG Chuanrong,et al.Materials and technology of solid rocket engine[M].Missile and Aerospace Series,Beijing:China Astronautic Publishing House,1995:135-136. [8] 王长辉,刘宇,覃粒子,等.多单元直排塞式喷管发动机性能研究[J].北京航空航天大学学报,2004,30(7):627-630.WANG Changhui,LIU Yu,QIN Lizi,et al.Performance analysis of linear clustered aerospike nozzles[J].Journal of Beijing University of Aeronautics and Astronautics,2004,30(7):627-630.
