弧齿锥齿轮齿根弯曲应力分析

李盛鹏; 方宗德; 张金良; 郭辉

弧齿锥齿轮齿根弯曲应力分析

西北工业大学机电学院, 西安 710072

基金项目: 国家自然科学基金(项目编号50475148);航空科学基金(项目编号04C53015)资助项目

计量
- 文章访问数: 1671
- HTML浏览量: 106
- PDF量: 455
- 被引次数: 0
出版历程
- 收稿日期: 2006-05-08
- 修回日期: 2006-10-19
- 刊出日期: 2007-05-28

Analysis of tooth root bending stress for spiral bevel gears

School of Mechatronic Engineering, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 运用自主开发的弧齿锥齿轮设计分析系统建立齿轮的轮齿网格模型, 并将模型数据变换后导入ANSYS软件中, 经过装配和结构扩展进行轮齿的接触分析, 最后得到了多齿对接触情况下, 齿根弯曲应力的分布和及其变化规律.利用所建立的弧齿锥齿轮的轮齿模型比采用Matlab、CAD软件(如I-DEAS or Pro-Engineer)得到模型更为准确.
- 航空、航天推进系统 /
- 弧齿锥齿轮 /
- 弯曲应力 /
- ANSYS
Abstract: Spiral bevel gear is an important transmission part in aero-engine,and the tooth root bending stress has direct effect on its natural life and safety.By using the analytical system of spiral bevel gear developed by the authors,the mesh grid models of spiral bevel gear were obtained.We use certain contact arithmetic of ANSYS to perform contact analysis of spiral bevel gear,and obtain the distributions and trend of variation of the tooth root bending stress.
- aerospace propulsion system /
- spiral bevel gear /
- bending stress /
- ANSYS

HTML

参考文献(8)

[1]	Dempsey P J,Handschuh R F,Afjeh A A.Spiral bevel gear damage detection using decision fusion analysis[R].NASA Technical Memorandum 211814,2002.
[2]	方宗德,杨宏斌.准双曲面齿轮弯曲应力过程的精确计算[J].汽车工程,2000,22(6):423-426.FANG Zongde,YANG Hongbin.Accurate calculation of time history of tooth bending stress for hypoid gears[J].Automotive Engineering,2002,22(6):423-426.
[3]	邓效忠,方宗德,魏冰阳.接触路径对弧齿锥齿轮接触应力和弯曲应力的影响[J].中国机械工程,2003,14(22):1895-1898.DENG Xiaozhong,FANG Zongde,WEI Bingyang.Analysis of contact stress and bending stress on spiral bevel gears of high contact ratio[J].China Mechanical Engineering,2003,14(22):1895-1898.
[4]	Litvin F L,Fuentes A,Fan Q,et al.Computerized design,simulation of meshing,and contact and stress analysis of face-milled formate generated spiral bevel gears[J].Mechanism and Machine Theory,2002 37:441-459.
[5]	邓效忠,方宗德,杨宏斌,等.高重合度弧齿锥齿轮的强度分析[J].航空动力学报,2002,17(3):367-372.DENG Xiaozhong,FANG Zongde,YANG Hongbin,et al.Analysis of meshing behavior and experiments of spiral bevel gears with high contact ratio[J].Journal of Aerospace Power,2002,17(3):367-372.
[6]	邓效忠,方宗德,张金良,等.弧齿锥齿轮的高重合度设计[J].中国机械工程,2002,13(9):791-795.DENG Xiaozhong,FANG Zongde,ZHANG Jingliang,et al.Design of spiral bevel gears with high contact ratio[J].China Mechanical Engineering,2002,13(9):791-795.
[7]	刘刚田,赵萍,杨耀山,等.弧齿锥齿轮的实体造型和有限元强度分析[J].矿山机械,2003,10:61-62.LIU Gangtian,ZHAO Ping,YANG Yaoshan,et al.Moulding of full size of the spiral bevel gears and its finite element strength analysis[J].Ming & Processing Equipment,2003,10:61-62.
[8]	龚曙光、谢桂兰.ANSYS操作命令与参数化编程[M].北京:机械工业出版社,2004.
