吹气型周向槽机匣处理扩稳机理的研究

基金项目: 国家航空科学基金资助(05C53016)

Mechanism of stall margin improvement associated with the blowing circumferential grooved casing treatment

School of Power and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要: 实验证明在周向环槽中加入切向吹气可以比原型处理机匣获得更大的稳定裕度.分别对带吹气型周向槽机匣处理与原型机匣处理的孤立转子进行全三维数值计算, 计算得到的总性能特性线同实验符合良好.通过详细地对比分析两种机匣处理的叶顶区域流场, 揭示了吹气型周向槽机匣处理比未吹气的原型机匣处理获得更大的稳定裕度和提高效率的机理.
- 航空、航天推进系统 /
- 轴流压气机 /
- 吹气型机匣处理 /
- 数值模拟 /
- 流场
Abstract: Tangent blowing in the circumferential grooves has the effect of achieving broader stall margin in the previous experiments.Three-dimentional numerical simulation has been performed for a subsonic axial-flow compressor rotor both with the blowing circumferential grooved casing treatment and archetypal casing treatment.The calculated overall performance lines showed good agreement with the experiments.The mechanism was that the blowing circumferential grooved casing treatment can achieve broader safety margin and improve the efficiency compared with archetypal casing treatment.This conclusion was obtained by detailed analyzing the flow-field at the blade tip of two kinds of casing treatment.
- aerospace propulsion system /
- axial-flow compressor /
- casing treatment with blowing /
- flow-field /

[1]	Horlock J H,Lakhwani C M.Propagating stall in compressor with porous walls[R].ASME Paper 75-GT-59,1975.
[2]	Rabe D C,Hah C.Application of casing circumferential grooves for improved stall margin in a transonic axial compressor[R].ASME Paper GT-2002-30641,2002.
[3]	Wilke I,Kau H P.A numerical investigation of the influence of casing treatments on the tip leakage flow in a HPC front stage[R].ASME Paper GT-2002-30642,2002.
[4]	刘志伟,张长生.周向槽机匣处理增加失速裕度的改进机理[J].西北工业大学学报,1986,4(4):405-415.LIU Zhiwei,ZHANG Changsheng.Mechanism of increasing stalled margin with the circumferential grooved casing treatment[J].Journal of Northwestern Polytechnical University,1986,4(4):405-415.
[5]	朱俊强.四种不同型式机匣处理的实验研究及机理分析[J].航空学报,1997,18(5):567-570.ZHU Junqiang.Experimental research on four kinds of treated casing[J].Acta Aeronautica et Astronautica Sinica,1997,18(5):567-570.
[6]	Wisier D C,Beacher B F.Improved compressor performance using recessed clearance[R].AIAA-86-1745,1986.
[7]	Fujita H,Takata H.A study on configurations of casing treatment for axial flow compressor[J].Bulletin of the JSME,1984,27(230):1675-1681.
