高超声速轴对称流道冷流特征及气动力特性研究

孙姝; 张红英; 王成鹏; 吕英伟; 程克明; 伍贻兆

高超声速轴对称流道冷流特征及气动力特性研究

南京航空航天大学高超气动研究中心(HARC), 南京 210016

基金项目: 国防科工委基础预研项目(A2520060219);中国博士后基金(0601042B);江苏省博士后基金(20060400935)

计量
- 文章访问数: 1806
- HTML浏览量: 159
- PDF量: 424
- 被引次数: 0
出版历程
- 收稿日期: 2007-01-08
- 修回日期: 2007-04-02
- 刊出日期: 2007-06-28

A study on the full flowpath and the aerodynamic characteristic of an axisymmetric hypersonic vehicle

Hypersonic Aerodynamics Research Center, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 对一种轴对称形式的高超声速飞行器全流道开展了风洞实验和数值模拟研究, 分析了不同来流总压、飞行攻角全流道的流场结构和气动力特性.研究结果表明:(1)一定范围内雷诺数的变化对全流道的流动结构和模型的气动力特性无显著影响, 因此所获得的风洞实验结果有望通过某种形式推广到飞行状态下使用;(2)飞行攻角对全流道的流动结构和升力系数有着显著影响, 但阻力系数的影响并不明显;(3)研究范围内来流马赫数的变化对全流道的流动结构有着一定影响, 但研究范围内, 阻力系数随马赫数的变化幅度较小;(4)由于轴对称流道的浸润面积较大, 研究范围内该类飞行器的摩擦阻力在全机阻力中占据了较大的比重, 设计状态下达全机气动力的62%;(5)与实验结果的对照表明, 所采用的数值模拟方法具有较高的精度.
- 航空、航天推进系统 /
- 轴对称形式高超飞行器 /
- 全流道 /
- 气动力特性 /
- 飞行攻角 /
- 来流马赫数
Abstract: Using the combined experiments and computational fluid dynamics(CFD),a study was carried out to investigate the aerodynamic characteristics and the full flowpath of an axisymmetric hypersonic vehicle.Results indicate:(1) Over the tested range the Reynold number brings no obvious influence on the flow pattern and the aerodynamics characteristic of the hypersonic vehicle.(2) Despite the fact that the drag coefficient is not sensitive to the change of the angle of attack,the lift coefficient and the flow structure of the full flowpath is highly affected.(3) With the increase of the free stream Mach number,the drag coefficient fluctuates slightly though changes can be found in the full flowpath.(4) Over the tested flight conditions the friction drag of the axisymmetric hypersonic vehicle occupies a significant proportion of the total aerodynamic drag and at the design condition the proportion reaches 62%.(5) The experimental results prove the reliabilities of the CFD.
- aerospace propulsion system /
- axisymmetric hypersonic vehicle /
- full flowpath /
- lift coefficient /
- drag coefficient /
- free stream Mach number

HTML

参考文献(14)

[1]	William H,Davis P.Hypersonic airbreathing propulsion[M].AIAA Education Series,AIAA Inc,USA,1994.
[2]	Bachchan N,Hillier R.Hypersonic inlet flow analysis at off-design conditions[R].AIAA 2004-5380.
[3]	Zanchetta M,Cain T.An axismmetric internal compression inlet[R].AIAA 1998-7957.
[4]	Hsia Yeu-Chuan.Full navier-stokes analysis of an axisymmetric seramjet inlet[J].Journal of Propulsion and Power,1993,9(4):826-833.
[5]	谭慧俊,郭荣伟.高超声速混合模块冲压发动机亚燃模块进气道的高焓风洞实验研究[J].航空学报,2007,28(4):686-693.TAN Huijun,GUO Rongwei.Wind tunnel tests of hypersonic inlets for ramjet models of the ramjet-scramjet combined engine[J].Acta Aeronautica et Astronaufica Sinica,2007,28(4):686-693.
[6]	Smart M K.Design of three-simensional hypersonic inlets with rectangular to elliptical shape transition[J].Journal of Propulsion and Power,1999,15(3):512-520.
[7]	Watanabe Y,Miyagi H,Sekido T.Conceptual design study on combine-cycle engine for hypersonic transport[R].ISABE-93-7018.
[8]	Voland R T,Auslender A H.CIAM/NASA Mach 6.5 Scramjet Flight and Ground Test[R].AIAA 1999-4848.
[9]	Roudakov A S,Semenov V L.Recent flight test results of the joint ClAM-NASA Mach 6.5 scramjet flight program[R].AIAA 1996-0357.
[10]	Billing F S.Shock-wave shapes around spherical-and cylindrical-nosed bodies[J].Journal of Spacecraft and Rockets,1967,4(6):822-823.
[11]	Edney B E.Effects of shock impingement of the heat transfer around blunt bodies[J].AIAA Journal,1986,16(1):15-21.
[12]	张红英,孙姝,程克明,等.进气道工作状态对吸气式高超飞行器气动力特性影响的实验研究[J].宇航学报,2007,28(4):624-628.ZHANG Hongying,SUN Shu,CHENG Keming,et al.Experimental investigation of inlet start/unstart influences on the aerodynamic characteristic of a hypersonic vehicle[J].Journal of Astronautics,2007,28(4):624-628.
[13]	孙姝,张红英,程克明,等.类X43-A飞行器全流道冷流流态的仿真及实验验证研究[J].航空学报,2007,28(6):912-917.SUN Shu,ZHANG Hongying,CHENG Keming,et al.A study of the full flowpath of a hypersonic vehicle[J].Acta Aeronautica et Astronautica Sinica,2007,28(6):912-917.
[14]	Tan H J,Guo R W.Experimental study of the unstableunstarted condition of a hypersonic inlet at Math 6[J].Journal of Propulsion and Power,2007,23(6):715-726.
